Are you looking for server-based data infrastructure with the highest density of storage capacity and balanced performance for bulk data-driven initiatives?
The HPE Alletra Storage Server 4140 is specifically designed to provide high throughput for the largest storage-centric workloads to power your data-driven initiatives. From deep archives and data protection to active analytics data lakes, file and object Software-Defined Storage, and so much more, the two chassis deliver the capabilities you need at ideal economics with trusted security and cloud-operating experience. Designed for high-density hybrid bulk storage, the HPE Alletra Storage Server 4140 supports up to 2.2 PB of storage in 4U. It includes the option to consume bulk storage as a service via GreenLake, enabling you to shift from owning and maintaining to simply utilizing it. The HPE Alletra Storage Server 4000 family of storage servers provides the data infrastructure for any successful data-driven organization.
Overview
What’s New
- – HPE NS204i-u v2 960 GB NVMe Hot Plug Boot-optimized Storage Device.
- – HPE NS204i-u v2 960 GB NVMe SED Hot Plug Boot-optimized Storage Device.
Notes: 1 4800 MT/s versus 3200 MT/s for the 3rd generation Intel® Xeon® Scalable processors.
Platform Information
Form Factor
- – 4U rack.
Chassis Types
- – Base model with 60 or 68 LFF SAS 24 Gb/SATA 6 Gb slots, depending on whether a rear drive cage is installed.
- – Extended model with 84 or 92 LFF SAS 24 Gb/SATA 6 Gb slots, depending on whether a rear drive cage is installed.
Notes:
– Optional Rear Drive Cages:
- 8 EDSFF E3S EC1 EDSFF NVMe x4 Rear Drive Cage.
- 4 SFF NVMe U.3 x4 Rear Drive Cage.
System Fans
6 system quad-fan modules shipped as standard.
Standard Features
Processors
Up to 2 of the following depending on model.
Notes:
– The 2nd digit of the processor model number “x4xx” is used to denote the processor generation (i.e., 4 = 4th generation).
– This table covers the public Intel offering only.
– For more information regarding Intel Xeon processors, please see the following http://www.intel.com/xeon.
| 5th Generation Intel® Xeon® Scalable Processor Family (Gold 6) | |||||||
|---|---|---|---|---|---|---|---|
| Intel Xeon Models | CPU Frequency | Cores | L3 Cache | Power | UPI | DDR5 | SGX Enclave size |
| Gold 6538N Processor | 2.1 GHz | 32 | 60 MB | 205 W | 3 @ 20 GT/s | 5200 MT/s | 128 GB |
| Gold 6526Y Processor | 2.8 GHz | 16 | 37.5 MB | 195 W | 3 @ 20 GT/s | 5200 MT/s | 128 GB |
| 5th Generation Intel® Xeon® Scalable Processor Family (Gold 5) | |||||||
|---|---|---|---|---|---|---|---|
| Intel Xeon Models | CPU Frequency | Cores | L3 Cache | Power | UPI | DDR5 | SGX Enclave size |
| Gold 5520+ Processor | 2.2 GHz | 28 | 52.5 MB | 205 W | 3 @ 20 GT/s | 4800 MT/s | 128 GB |
| Gold 5515+ Processor | 3.2 GHz | 8 | 22.5 MB | 165 W | 3 @ 20 GT/s | 4800 MT/s | 128 GB |
| Gold 5512U Processor | 2.1 GHz | 28 | 52.5 MB | 185 W | N/A | 4800 MT/s | 128 GB |
| 4th Generation Intel® Xeon® Scalable Processor Family (Gold) | |||||||
|---|---|---|---|---|---|---|---|
| Intel Xeon Models | CPU Frequency | Cores | L3 Cache | Power | UPI | DDR5 | SGX Enclave size |
| Gold 6438Y+ Processor | 2.0 GHz | 32 | 60 MB | 205 W | 3 @ 16 GT/s | 4800 MT/s | 128 GB |
| Gold 6426Y Processor | 2.5 GHz | 16 | 37.5 MB | 185 W | 3 @ 16 GT/s | 4800 MT/s | 128 GB |
| Gold 5420+ Processor | 2.0 GHz | 28 | 52.5 MB | 205 W | 3 @ 16 GT/s | 4400 MT/s | 128 GB |
| Gold 5418Y Processor | 2.0 GHz | 24 | 45 MB | 185 W | 3 @ 16 GT/s | 4400 MT/s | 128 GB |
| Gold 5418N Processor | 1.8 GHz | 24 | 45 MB | 165 W | 3 @ 16 GT/s | 4000 MT/s | 128 GB |
| Gold 5416S Processor | 2.0 GHz | 16 | 30 MB | 150 W | 3 @ 16 GT/s | 4400 MT/s | 128 GB |
| Gold 5415+ Processor | 2.9 GHz | 8 | 22.5 MB | 150 W | 3 @ 16 GT/s | 4400 MT/s | 128 GB |
| Gold 5412U Processor | 2.1 GHz | 24 | 45 MB | 185 W | N/A | 4400 MT/s | 128 GB |
Notes:
– 2 socket capable, 2S - 4 or 3 UPI @ 20 or 16 GT/s, except U SKUs.
– 4th and 5th Generation: 8-Channel DDR5 1DPC @ 5200 – 4000 MT/s.
– 80 lanes PCIe 5.0, advanced RAS.
– Y SKUs support Intel Speed Select Technology – Performance Profile 2.0 (Intel SST-PP).
– U SKUs supported in one-socket configurations only.
– S SKUs are storage & hyperconverged infrastructure (HCI) optimized SKUs.
– N SKUs support Intel QuickAssist Technology (QAT).
– + Feature Plus: Support AMX, DLB, DSA, IAA and QAT additionally.
| 5th Generation Intel® Xeon® Scalable Processor Family (Silver) | |||||||
|---|---|---|---|---|---|---|---|
| Intel Xeon Models | CPU Frequency | Cores | L3 Cache | Power | UPI | DDR5 | SGX Enclave size |
| Silver 4516Y+ Processor | 2.2 GHz | 24 | 45 MB | 185 W | 2 @ 16 GT/s | 4400 MT/s | 64 GB |
| Silver 4514Y Processor | 2.0 GHz | 16 | 30 MB | 150 W | 2 @ 16 GT/s | 4400 MT/s | 64 GB |
| Silver 4510 Processor | 2.0 GHz | 12 | 30 MB | 150 W | 2 @ 16 GT/s | 4400 MT/s | 64 GB |
| Silver 4509Y Processor | 2.6 GHz | 8 | 22.5 MB | 125 W | 2 @ 16 GT/s | 4400 MT/s | 64 GB |
| 4th Generation Intel® Xeon® Scalable Processor Family (Silver) | |||||||
|---|---|---|---|---|---|---|---|
| Intel Xeon Models | CPU Frequency | Cores | L3 Cache | Power | UPI | DDR5 | SGX Enclave size |
| Silver 4416+ Processor | 2.0 GHz | 20 | 37.5 MB | 165 W | 2 @ 16 GT/s | 4000 MT/s | 64 GB |
| Silver 4410Y Processor | 2.0 GHz | 12 | 30 MB | 150 W | 2 @ 16 GT/s | 4000 MT/s | 64 GB |
Notes:
− 2 socket capable, 2S - 2 UPI @ 16 GT/s, except U SKUs.
− 4th Generation: 8-Channel DDR5 @ 4000 MT/s.
− 80 lanes PCIe 5.0, advanced RAS.
− Y SKUs support Intel Speed Select Technology – Performance Profile 2.0 (Intel SST-PP).
− + Feature Plus: Support AMX, DLB, DSA, IAA and QAT additionally.
| 5th Generation Intel® Xeon® Scalable Processor Family (Bronze) | |||||||
|---|---|---|---|---|---|---|---|
| Intel Xeon Models | CPU Frequency | Cores | L3 Cache | Power | UPI | DDR5 | SGX Enclave size |
| Bronze 3508U Processor | 2.1 GHz | 8 | 22.5 MB | 125 W | N/A | 4400 MT/s | 64 GB |
| 4th Generation Intel® Xeon® Scalable Processor Family (Bronze) | |||||||
|---|---|---|---|---|---|---|---|
| Intel Xeon Models | CPU Frequency | Cores | L3 Cache | Power | UPI | DDR5 | SGX Enclave size |
| Bronze 3408U Processor | 1.8 GHz | 8 | 22.5 MB | 125 W | N/A | 4000 MT/s | 64 GB |
Notes:
– 4th Generation: 8-Channel DDR5 @ 4000 MT/s.
– 80 lanes PCIe 5.0, advanced RAS.
– U SKUs supported in one-socket configurations only.
Chipset
Intel C741 Chipset.
Notes: For more information regarding Intel® chipsets, please see the following URL:
http://www.intel.com/products/server/chipsets/.
On System Management Chipset
HPE iLO 6 ASIC.
Notes: Read and learn more in the iLO QuickSpecs.
Memory | |
| Type | HPE DDR5 Smart Memory Registered (RDIMM) |
| DIMM Slots Available | 24 12 DIMM slots per processor, 8 channels per processor, 2-2-1-1 deployment |
| Maximum capacity (RDIMM) | 1.5 TB 24 x 64 GB RDIMM @ 5200 or 4800 MT/s |
Notes:
– The maximum memory speed is limited by the processor selection.
– The maximum capacity per system is limited by the overall configuration selection due to thermal capacity.
Memory Protection
Advanced ECC
Advanced ECC uses single device data correction to detect and correct single and all multibit errors that occur within a single DRAM chip.
Internal Storage Devices
- – Hard Drives
- None shipped as standard.
Storage Controllers
NVMe Boot Devices
- – Optional HPE NS204i-u Gen11 NVMe Hot Plug Boot-optimized Storage Device.
- – Optional HPE NS204i-u v2 960 GB NVMe Hot Plug Boot-optimized Storage Device.
- – Optional HPE NS204i-u v2 960 GB NVMe SED Hot Plug Boot-optimized Storage Device.
Notes:
– NS204i-u does not occupy a PCIe slot.
– Two 480 GB, 960 GB or 960 GB SED M.2 NVMe SSD drives are included in the NS204i-u Gen11 or v2 Hot Plug Boot Device.
– Hardware RAID 1 supported on the NS204i-u Gen11 or v2 Hot Plug Boot Device.
Smart Array Controller
- – HPE Alletra 41X0 SR 32-port PCIe FIO Storage Controller.
- Notes: Only available for factory integration.
- – HPE SR932i-p Gen11 x32 Lanes 8 GB Wide Cache PCI SPDM Plug-in Storage.
- Notes: Suggested for field upgrade only.
- – HPE Smart Array E208e-p SR Gen10 Storage Controller.
- Notes: Used for attaching external storage devices such as JBODs and tape drives.
Notes: For additional details, please visit: HPE Compute SR Gen11 Controllers QuickSpecs.
Maximum Internal Storage
| Maximum Storage | ||
|---|---|---|
| Storage | Capacity | Configuration |
| 68 LFF with no rear cage | 1,632 TB | 68 x 24 TB SAS/SATA |
| 60 LFF with 8 EDSFF NVMe rear cage | 1,562 TB | 60 x 24 TB SAS/SATA + 8 x 15.36 TB EDSFF |
| 60 LFF with 4 SFF NVMe rear cage | 1,501 TB | 60x 24 TB SAS/SATA + 4 x 15.35 TB NVMe |
| 92 LFF with no rear cage | 2,208 TB | 92x 24 TB SAS/SATA |
| 84 LFF with 8 EDSFF NVMe rear cage | 2,138 TB | 84 x 24 TB SAS/SATA + 8 x 15.36 TB EDSFF |
| 84 LFF with 4 SFF NVMe rear cage | 2,077 TB | 84 x 24 TB SAS/SATA + 4 x 15.36 TB NVMe |
Internal Storage Devices
- – Hard Drives.
- – None shipped as standard.
Graphics
– Integrated video (standard).
- Video modes up to 1920 x 1200 @ 60 Hz (32 bpp).
- 16 MB Video Memory.
– HPE iLO 6 on system management memory.
- 32 MB Flash.
- 4 Gbit DDR3 with ECC protection.
Power Supply
- – HPE 1000 W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit.
- Notes: Available in 96% efficiency.
- – HPE 1600 W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit.
- Notes:
- – Available in 94% efficiency.
- – 1600 W Power supplies only support high line voltage (200 VAC to 240 VAC).
- – HPE 1800-2200 W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit.
- Notes:
- – Available in 96% efficiency.
- – 1800-2200 W Power supplies only support high line voltage (200 VAC to 240 VAC).
HPE Flexible Slot (Flex Slot) Power Supplies share a common electrical and physical design that allows for hot plug, tool-less installation into HPE ProLiant Performance Servers. Flex Slot power supplies are certified for high-efficiency operation and offer multiple power output options, allowing users to "right-size" a power supply for specific server configurations. This flexibility helps to reduce power waste, lower overall energy costs, and avoid trapped power capacity in the data center.
All pre-configured servers ship with a standard 6-foot IEC C-13/C-14 jumper cord (A0K02A). This jumper cord is also included with each standard AC power supply option kit. If a different power cord is required, please check the ProLiant Power Cables web page.
To review the power requirements for your selected system, please use the HPE Power Advisor Tool.
For information on power specifications and technical content visit HPE Server power supplies.
Interfaces | |
| Serial | 1 port – Optional, rear |
| VGA Port | 1 port – Standard, rear |
| Network Ports | None. Choice of OCP or standup PCIe card, supporting a wide range of NIC adapters |
| HPE iLO Remote Management Network Port | 1 GbE Dedicated |
| Front iLO Service Port | 1 standard |
| USB 3.0 | 5 standard on all models: 1 front, 2 rear, 2 internal |
Operating Systems and Virtualization Software
- – Windows Server 2019
- – Windows Server 2022
- – Windows Server 2025
- – Red Hat Enterprise Linux (RHEL) 8.6
- – Red Hat Enterprise Linux (RHEL) 9.0
- – Red Hat Enterprise Linux (RHEL) 10.0
- – SUSE Linux Enterprise Server (SLES) 15 SP4
- – SUSE Linux Enterprise Server (SLES) 16
- – SUSE Linux Enterprise Server (SLES) 15 SP5 QU1
- – SUSE Linux Enterprise Server (SLES) SL Micro 6.2
- – SUSE Linux Enterprise Server (SLES) SL Micro 5.5
- – VMware 7.0 U3
- – VMware 8.0 U1, U2, U3
- – VMware 9.0
- – VMware 9.1
- – Canonical Ubuntu 20.04.5 (5.15.0)
- – Canonical Ubuntu 22.04 (5.15.0)
- – Canonical Ubuntu 24.04 LTS
Notes: For more information on Hewlett Packard Enterprise Certified and Supported ProLiant Servers for OS and Virtualization Software and latest listing of software drivers available for your server visit: http://www.HPE.com/info/ossupport
Industry Standard Compliance
- – ACPI6.4 Compliant
- – PCIe5.0 Compliant
- – WOL Support
- – Microsoft® Logo certifications
- – PXE Support
- – USB 3.2 Gen1 Compliant
- – SMBIOS 3.4
- – Redfish API
- – IPMI 2.0
- – Secure Digital 4.0
- – TPM 2.0 support
- – Advanced Encryption Standard (AES)
- – Triple Data Encryption Standard (3DES)
- – SNMP v3
- – TLS 1.2
- – DMTF Systems Management Architecture for Server Hardware Command Line (SMASH CLP)
- – One Button Secure Erase Enhancements
- Notes:
- – For additional technical, thermal details regarding ambient temperature, humidity, and feature support, please visit: http://www.HPE.com/servers/ashrae
- – At Standard Operating Support conditions, there is no time limitation for operating the servers in ASHRAE Class A2 conditions, unless otherwise specified in the applicable product information.
- – UEFI (Unified Extensible Firmware Interface Forum) 2.7 – Red Hat
Embedded Management
HPE Integrated Lights-Out (HPE iLO)
Monitor your servers for ongoing management, service alerting, reporting and remote management with HPE iLO.
Learn more at: http://www.HPE.com/info/ilo.
UEFI
Configure and boot your servers securely with industry standard Unified Extensible Firmware Interface (UEFI).
Learn more at: http://www.HPE.com/servers/uefi.
Intelligent Provisioning
Streamlined server and Operating System provisioning for one or more servers with Intelligent Provisioning. Learn more at: http://www.HPE.com/servers/intelligentprovisioning.
iLO RESTful API
iLO RESTful API is Redfish API conformance and offers simplified server management automation such as configuration and maintenance tasks based on modern industry standards. Learn more at: http://www.HPE.com/info/restfulapi.
Server Utilities
Active Health System
The HPE Active Health System (AHS) is an essential component of the iLO management portfolio that provides continuous, proactive health monitoring of HPE servers. Learn more at: http://www.HPE.com/servers/ahs.
Active Health System Viewer
Use the Active Health System Viewer, a web-based portal, to easily read AHS logs and speed problem resolution with HPE self-repair recommendations, to learn more visit: http://www.HPE.com/servers/ahsv.
Smart Update
Keep your servers up to date with the HPE Smart Update solution by using Smart Update Manager (SUM) to optimize the firmware and driver updates of the Service Pack for ProLiant (SPP). Learn more at:
https://www.HPE.com/us/en/servers/smart-update.html
iLO Amplifier Pack
Designed for large enterprise and service provider environments with hundreds of HPE servers, the iLO Amplifier Pack is a free, downloadable open virtual application (OVA) that delivers the power to discover, inventory and update Gen8, Gen9, Gen10 and Gen11 HPE servers at unmatched speed and scale. Use with an iLO Advanced License to unlock full capabilities. Learn more at: http://www.HPE.com/servers/iLOamplifierpack.
HPE iLO Mobile Application
Enables the ability to access, deploy, and manage your server anytime from anywhere from select smartphones and mobile devices. For additional information please visit: http://www.HPE.com/info/ilo/mobileapp.
RESTful Interface Tool
RESTful Interface tool (iLOREST) is a single scripting tool to provision using iLO RESTful API to discover and deploy servers at scale. Learn more at: http://www.HPE.com/info/resttool.
Scripting Tools
Provision one-to-many servers using your own scripts to discover and deploy with Scripting Tool (STK) for Windows and Linux or Scripting Tools for Windows PowerShell. Learn more at: http://www.HPE.com/servers/powershell.
HPE OneView Standard
HPE OneView Standard can be used for inventory, health monitoring, alerting, and reporting without additional fees. It can monitor multiple HPE server generations. The user interface is similar to the HPE OneView Advanced version, but the software-defined functionality is not available. Learn more at: http://www.HPE.com/info/oneview.
HPE Compute Ops Management
HPE is intelligently transforming compute management with a completely new as a service experience that delivers greater security, simplicity, and efficiency. Discover a completely modernized compute management experience delivered through GreenLake that securely streamlines operations from edge-to-cloud, and automates key lifecycle tasks (onboard, update, manage and monitor HPE servers), bringing the agility and greater efficiencies to wherever compute devices reside via a unified single browser-based interface.
HPE Compute Ops Management is built on a unique cloud-native architecture that abstracts, manages and controls HPE servers regardless of physical location. The management application resides in the GreenLake cloud platform (access via: https://console.greenlake.HPE.com) and leverages the GreenLake architecture, security, and unified operations.
Security
- – UEFI Secure Boot and Secure Start support
- – Immutable Silicon Root of Trust
- – FIPS 140-2 validation
- – Common Criteria certification
- – Configurable for PCI DSS compliance
- – Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser
- – Support for Commercial National Security Algorithms (CNSA)
- – iLO Security Modes
- – Granular control over iLO interfaces
- – Smart card (PIV/CAC) and Kerberos based 2-factor Authentication
- – Tamper-free updates – components digitally signed and verified
- – Secure Recovery – recover critical firmware to known good state on detection of compromised FW
- – Ability to roll back firmware
- – Secure erase of NAND
- – TPM (Trusted Platform Module) 2.0 option
- – Bezel Locking Kit
- – Chassis Intrusion detection
HPE Trusted Platform Module
HPE Trusted Platform Module 2.0 is included on Pre-Configured models and can be enabled and disabled using the BIOS.
Notes: The TPM (Trusted Platform Module) is a microcontroller chip that can securely store artifacts used to authenticate the server platform. These artifacts can include passwords, certificates and encryption keys.
Warranty
This product is covered by a global limited warranty and supported by HPE Services and a worldwide network of HPE Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HPE Service operational services or customized service agreements. Hard drives have either a one-year or three-year warranty; refer to the specific hard drive QuickSpecs for details.
Notes: Server warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have Hewlett Packard Enterprise replace Optional CSR parts at no additional cost. Additional information regarding worldwide limited warranty and technical support is available at:
https://support.HPE.com/hpesc/public/docDisplay?docId=sd00004309en_us&docLocale=en_US.
Server Management
HPE iLO Advanced
HPE iLO Advanced licenses offer smart remote functionality without compromise, for all HPE ProLiant servers. The license includes the full integrated remote console, virtual keyboard, video, and mouse (KVM), multi-user collaboration, console record and replay, and GUI-based and scripted virtual media and virtual folders. You can also activate the enhanced security and power management functionality.
HPE iLO Advanced Premium Security Edition
HPE iLO Advanced Premium Security Edition for iLO 5 includes iLO Advanced License plus high-end security modes, unique security capabilities, like Automatic FW recovery; Runtime FW verification, and Secure erase. Learn more about HPE iLO Advanced Premium Security Edition at:
HPE OneView Advanced
HPE OneView brings a new level of automation to infrastructure management by taking a template-driven approach to provisioning, updating, and integrating compute, storage, and networking infrastructure. It provides full-featured licenses which can be purchased for managing Gen8, Gen9, Gen10 and Gen11 servers. To
learn more visit: http://www.HPE.com/info/oneview.
HPE Insight Cluster Management Utility (CMU)
HPE Insight Cluster Management Utility is a HyperScale management framework that includes software for the centralized provisioning, management and monitoring of nodes and infrastructure. Learn more at:
Rack and Power Infrastructure
The story may end with servers, but it starts with the foundation that makes compute go – and business grow. We’ve reinvented our entire portfolio of rack and power products to make IT infrastructure more secure, more practical, and more efficient. In other words, we’ve created a stronger, smarter, and simpler infrastructure to help you get the most out of your IT equipment. As an industry leader, Hewlett Packard Enterprise is uniquely positioned to address the key concerns of power, cooling, cable management and system access.
HPE G2 Advanced and Enterprise Racks are perfect for the server room or today’s modern data center with enhanced airflow and thermal management, flexible cable management, and a 10-year Warranty to support higher density computing.
HPE G2 PDUs offer reliable power in flexible form factors that operate at temperatures up to 60°, include color-coded outlets and load segments and a low-profile design for optimal access to the rack and support for dense rack environments.
HPE Uninterruptible Power Systems are cost-effective power protection for any type of workload. Some UPSs include options for remote management and extended runtime modules, so your critical dense data center is covered in power outages.
HPE KVM Solutions include a console and switches designed to work with your server and IT equipment reliably. We have a cost-effective KVM switch for your first rack and multiple connection IP (Idle Power) switches with remote management and security capabilities to keep your data center rack up and running.
Learn more about HPE Racks, KVM, PDUs and UPSs at HPE Rack and Power Infrastructure.
Notes:
− Rack fitment of HPE Alletra Storage Servers is optimized for HPE G2 Series Racks, HPE rail kits, HPE cables and HPE power distribution units.
− Proper rack fitment of HPE Alletra Storage Servers in third-party racks using third-party racking options is the sole responsibility of the customer. Consult the HPE Alletra Storage Server 4140 Setup and Installation Guide, Mechanical specifications section, for fitment planning.
One Config Simple (SCE)
SCE is a guided self-service tool to help sales and non-technical people provide customers with initial configurations in 3 to 5 minutes. You may then send the configuration on for configuration help or use in your existing ordering processes. If you require "custom" rack configuration or configuration for products not available in SCE, please contact Hewlett Packard Enterprise Customer Business Center or an Authorized Partner for assistance:
Service and Support
For the most up-to-date information on HPE Services, please refer to the HPE Services – Supplemental QuickSpecs, which provides a comprehensive and regularly updated overview of available services.
Configuration Information
This section lists some of the steps required to configure a Factory Integrated Model.
To ensure valid configurations are ordered, Hewlett Packard Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative for information on configurable product offerings and requirements.
- – Factory Integrated Models must start with a CTO Server.
- – FIO indicates that this option is only available as a factory installable option.
- – Some options may not be integrated at the factory. Contact your local sales representative for additional information
Step 1: Base Configuration (choose one of the following configurable models)
Network Choice (NC) Models
Network Choice models do not include embedded LOM. To enable networking capability please select a validated alternative NIC -OCP or PCIe- from the Core Options section.
| CTO Models | HPE Alletra Storage Server 4140 68 LFF Configure-to-order System | HPE Alletra Storage Server 4140 92 LFF Configure-to-order System |
|---|---|---|
| SKU Number | P63103-B21 | P63253-B21 |
| TAA SKU* | P63103-B21#GTA | P63253-B21#GTA |
| Processor | Not included as standard | |
| DIMM Slots | 24-DIMM slots | |
| Storage Controller | One or two SR 32-Port PCIe FIO Storage Controllers are required | One or Two SR 32-Port PCIe FIO Storage Controllers are required |
| PCIe | Up to 4 PCIe slots | |
| Rear Drive Cage Options | P63129-B21 - HPE Alletra Storage Server 4140 8EDSFF E3.S Thin Carrier Rear Drive Cage FIO Kit P63131-B21 - HPE Alletra Storage Server 4140 4SFF PCIe x4 U.3 BC Rear Drive Cage FIO Enablement Kit | |
| Network Controller | Choice of OCP or stand-up PCIe cards Notes: No embedded networking. | |
| Fans | 6 quad-rotor fan modules | |
| Management | Default: HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (requires download), HPE Compute Ops Management (subscription included) | |
| USB | Front: 1 USB 3.0 + iLO service port Rear: 2 USB 3.0 Internal: 2 USB 3.0 | |
| Form Factor | 4 U Rack | |
| Warranty | 3-year parts, 3-year labor, 3-year onsite support with next business day response. | |
Notes: *HPE offers multiple Trade Agreement Act (TAA) compliant configurations to meet the needs of US Federal Government customers. These products are either manufactured or substantially transformed in a designated country.
Step 2: Choose Required OptionsPlease select one or two matching processors for either HPE Alletra Storage Server 4140 system. | |
| Notes: – Mixing of two different processor models is not supported. – All Processors require the HPE Alletra Storage Server 4140 CPU Heat Sink (P64001-B21). | |
| Step 2a: Choose Processor Options | |
| Processor Option Kits | |
| 5th Generation Intel Xeon-Gold | SKU |
| Intel Xeon-Gold 6538N 2.1GHz 32-core 205W Processor Kit for HPE Alletra Storage Server 41X0 | P67412-B21 |
| Intel Xeon-Gold 6526Y 2.8GHz 16-core 195W Processor Kit for HPE Alletra Storage Server 41X0 | P67418-B21 |
| Intel Xeon-Gold 5520+ 2.2GHz 28-core 205W Processor Kit for HPE Alletra Storage Server 41X0 | P67413-B21 |
| Intel Xeon-Gold 5515+ 3.2GHz 8-core 165W Processor Kit for HPE Alletra Storage Server 41X0 | P67402-B21 |
| Intel Xeon-Gold 5512U 2.1GHz 28-core 185W Processor Kit for HPE Alletra Storage Server 41X0 | P67414-B21 |
| 5th Generation Intel Xeon-Silver | SKU |
| Intel Xeon-Gold 5512U 2.1GHz 28-core 185W Processor Kit for HPE Alletra Storage Server 41X0 | P67414-B21 |
| Intel Xeon-Silver 4516Y+ 2.2GHz 24-core 185W Processor Kit for HPE Alletra Storage Server 41X0 | P67416-B21 |
| Intel Xeon-Silver 4514Y 2.0GHz 16-core 150W Processor Kit for HPE Alletra Storage Server 41X0 | P67419-B21 |
| Intel Xeon-Silver 4510 2.4GHz 12-core 150W Processor Kit for HPE Alletra Storage Server 41X0 | P67420-B21 |
| Intel Xeon-Silver 4509Y 2.6GHz 8-core 125W Processor Kit for HPE Alletra Storage Server 41X0 | P67403-B21 |
| 5th Generation Intel Xeon-Bronze | SKU |
| Intel Xeon-Bronze 3508U 2.1GHz 8-core 125W Processor Kit for HPE Alletra Storage Server 41X0 | P67404-B21 |
| Notes: U Supported in one-socket configurations only | |
| 4th Generation Intel Xeon-Gold | SKU |
| Intel Xeon-Gold 6438Y+ 2.0GHz 32-core 205W Processor Kit for HPE Alletra Storage Server 41X0 | P50806-B21 |
| Intel Xeon-Gold 6426Y 2.5GHz 16-core 185W Processor Kit for HPE Alletra Storage Server 41X0 | P50794-B21 |
| Intel Xeon-Gold 5420+ 2.0GHz 28-core 205W Processor Kit for HPE Alletra Storage Server 41X0 | P50804-B21 |
| Intel Xeon-Gold 5418Y 2.0GHz 24-core 185W Processor Kit for HPE Alletra Storage Server 41X0 | P50803-B21 |
| Intel Xeon-Gold 5418N 1.8GHz 24-core 165W Processor Kit for HPE Alletra Storage Server 41X0 | P50816-B21 |
| Intel Xeon-Gold 5416S 2.0GHz 16-core 150W Processor Kit for HPE Alletra Storage Server 41X0 | P50808-B21 |
| Intel Xeon-Gold 5415+ 2.9GHz 8-core 150W Processor Kit for HPE Alletra Storage Server 41X0 | P50793-B21 |
| Intel Xeon-Gold 5412U 2.1GHz 24-core 185W Processor Kit for HPE Alletra Storage Server 41X0 | P50812-B21 |
| Notes: U Supported in one-socket configurations only | |
| 4th Generation Intel Xeon-Silver | SKU |
| Notes: All SKUs below ship with processor only. 4000 MT/s maximum memory speed unless otherwise noted. | |
| Intel Xeon-Silver 4416+ 2.0GHz 20-core 165W Processor Kit for HPE Alletra Storage Server 41X0 | P50802-B21 |
| Intel Xeon-Silver 4410Y 2.0GHz 12-core 150W Processor Kit for HPE Alletra Storage Server 41X0 | P50801-B21 |
| 4th Generation Intel Xeon-Bronze | SKU |
| Notes: All SKUs below ship with processor only. 4000 MT/s maximum memory speed unless otherwise noted. | |
| Intel Xeon-Bronze 3408U 1.8GHz 8-core 125W Processor Kit for HPE Alletra Storage Server 41X0 | P50811-B21 |
| Notes: U Supported in one-socket configurations only. | |
Step 2b: Choose Memory OptionsPlease select one or more memory from below. For additional information, please see the HPE DDR5 Smart Memory QuickSpecs. | |
| Notes: – The maximum memory speed and capacity is a function of the memory type, memory configuration, and processor model. – Quantity of memory DIMMs selected per socket must be 1, 2, 4, 6, 8, or 12. – Mixing of 3DS and non-3DS DIMMs not allowed. – The 5600 MT/s Memory SKUs are supported for 5th Gen processors only. – The 4800 MT/s Memory SKUs are supported for 4th Gen processors only. – The -K21 memory SKUs shown in this document are to be used when ordering stand-alone memory only. For each -K21 SKU, there is a corresponding -F21 SKU which is to be used when configuring servers with integrated memory DIMMs. | |
| Registered DIMMs (RDIMMs) | |
| Notes: – The mixing of 3DS and non-3DS DIMMs is not allowed. – Rank Mixing is not supported. | |
| Description | SKU |
| HPE 16GB (1x16GB) Single Rank x8 DDR5-5600 CAS-46-45-45 EC8 Registered Smart Memory Kit | P64705-K21 |
| HPE 32GB (1x32GB) Dual Rank x8 DDR5-5600 CAS-46-45-45 EC8 Registered Smart Memory Kit | P64706-K21 |
| HPE 64GB (1x64GB) Dual Rank x4 DDR5-5600 CAS-46-45-45 EC8 Registered Smart Memory Kit | P64707-K21 |
| Notes: Mixing of different DDR5-5600 DIMM capacities is NOT allowed. | |
| HPE 16GB (1x16GB) Single Rank x8 DDR5-4800 CAS-40-39-39 EC8 Registered Smart Memory Kit | P43322-K21 |
| HPE 32GB (1x32GB) Dual Rank x8 DDR5-4800 CAS-40-39-39 EC8 Registered Smart Memory Kit | P43328-K21 |
| HPE 64GB (1x64GB) Dual Rank x4 DDR5-4800 CAS-40-39-39 EC8 Registered Smart Memory Kit | P43331-K21 |
| Notes: Mixing different DDR5-4800 DIMM capacities is NOT allowed | |
| Step 2c: Choose Power Supplies | |
| Please select up to 4 power supplies from below. | |
| Notes: Mixing different power supplies is NOT allowed | |
| HPE Flex Slot Power Supplies | SKU |
| HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit | P03178-B21 |
| HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit | P38997-B21 |
| HPE 1800W-2200W Flex Slot Titanium Hot Plug Power Supply Kit | P44712-B21 |
| Notes: Only supports high line voltage (200 VAC to 240 VAC). | |
Step 3 : Choose Additional (FIO) Factory Integratable Options | |
| Each of the following may be selected if desired at time of factory integration | |
| Description | SKU |
| HPE Smart Memory Fast Fault Tolerance FIO Setting | 875293-B21 |
| Notes: – Enables Fast Fault Tolerance mode, an HPE Memory RAS feature introduced in HPE Gen10 servers that survives up to two DRAM failures. – This RAS feature combines Adaptive Double DRAM Device Correction (ADDC) with HPE Advanced Error Detection Technology, resulting in significantly better memory reliability and availability than what ADDDC provides on its own. For more information see our Memory RAS feature technical whitepaper. | |
| HPE Security Options | |
| HPE Server Security Optimized Service for HPE ProLiant (R9S59A) is an optional security upgrade intended for agencies and regulated industries with enhanced security and compliance needs. Applying this option to a HPE Alletra 41X0 CTO system ensures it is hardened by turning on advanced safeguards in place against cyber-exploits throughout the server lifecycle. An iLO Advanced License required for High Security Mode and compatible intrusion detection device option kits are prerequisites for the full optimization service. | |
Step 4: Management softwareSelect your choice of cloud-native management or on-premises management software. HPE Compute Ops Management for cloud-native management Notes: HPE Compute Ops Management for cloud-native management of Alletra Storage Servers, as well as ProLiant servers. The SKUs below are for Alletra Storage Servers specifically, and are billed upfront. If you want to be billed monthly or annually, please order R6Z73AAE standalone. | |
| Recommended SKU | SKU |
| HPE Compute Ops Management Standard 5-year Upfront Alletra 4000 SaaS | S1E13AAE |
| Alternative SKUs | SKU |
| HPE Compute Ops Management Standard 3-year Upfront Alletra 4000 SaaS | S1E12AAE |
| HPE Compute Ops Management Advanced 3-year Upfront Alletra 4000 SaaS | S5E63AAE |
| HPE Compute Ops Management Advanced 5-year Upfront Alletra 4000 SaaS | S5E64AAE |
| Notes: The COM Advanced SKUs also include an iLO Advanced license and support so a standalone iLO Advanced license does not need to be ordered separately. | |
| Required SKU when ordering through GreenLake Flex: | SKU |
| HPE Compute Ops Management Standard with Alletra 4000 Enablement | S4P39AAE |
| Notes: Both the tracking SKU above as well as one of the COM SaaS SKUs (S1E13AAE or S1E12AAE) are needed to allow COM to be included and transacted as part of a GL Flex solution and contracts. | |
| HPE OneView | SKU |
| HPE OneView including 3yr 24x7 Support Flexible Quantity E-LTU | E5Y35AAE |
| HPE OneView w/o iLO including 3yr 24x7 Support Flexible Quantity E-LTU | P8B26AAE |
Additional Options
Some options may not be integrated at the factory. To ensure only valid configurations are ordered, Hewlett Packard Enterprise recommends the use of a Hewlett Packard Enterprise approved configurator. Contact your local sales representative for additional information.
HPE Unique Options | |
| Heat Sink | SKU |
| HPE Alletra Storage Server 4140 CPU Heat Sink Kit | P64001-B21 |
| Notes: Required for all processors. | |
| System FIO Storage Controllers | SKU |
| HPE Alletra Storage Server 41X0 SR 32-port PCIe FIO Storage Controller | P61479-B21 |
| Notes: Minimum of one is required to connect to LFF drives in the drawers. | |
| Optional Rear Drive Cage If desired, please select one of the two optional NVMe rear drive cages available from below. These rear drive cages must be installed in the factory. The NVMe SSDs in either of these cages can be directly connected to the processors or can be connected through one or two storage controllers. | |
| Description | SKU |
| HPE Alletra Storage Server 4140 8EDSFF E3.S Thin Carrier Rear FIO Drive Cage Kit | P63129-B21 |
| Notes: Initially, this rear cage option will not support VROC with only one processor and direct-attached drives. Use either two processors or connect the EDSFF drives through a storage controller. | |
| HPE Alletra Storage Server 4140 4SFF PCIe x4 U.3 BC Rear Drive Cage FIO Enablement Kit | P63131-B21 |
| Rear Drive Cage Cables | SKU |
| Notes: – One of the Rear Drive Cage Cable must be selected when Rear Drive Cage Upgrade SKU is selected. – If no rear cage is selected, no cable is required. – Choose a cable based on the rear cage type, whether there is 1 processor or two, and if the rear drives are to be directly connected to the processor(s) or through storage controller(s) as indicated in the description. | |
| HPE Alletra Storage Server 4140 1P 4SFF Rear Drive Cage Controller Attached Cable Kit | P64677-B21 |
| HPE Alletra Storage Server 4140 1P 4SFF Rear Drive Cage Direct Attached Cable Kit | P64679-B21 |
| HPE Alletra Storage Server 4140 1P 8EDSFF Rear Drive Cage Controller Attached Cable Kit | P64683-B21 |
| HPE Alletra Storage Server 4140 1P 8EDSFF Rear Drive Cage Direct Attached Cable Kit | P64685-B21 |
| Notes: Initially, this rear cage cable option will not support VROC. | |
| HPE Alletra Storage Server 4140 2P 8EDSFF Rear Drive Cage Direct Attached Cable Kit | P65897-B21 |
| HPE Alletra Storage Server 4140 2P 4SFF Rear Drive Cage Balanced Controller Attached Cable Kit | P64687-B21 |
| Notes: When this SKU is selected, the 2nd processor and two storage controllers are required. | |
| HPE Alletra Storage Server 4140 2P 4SFF Rear Drive Cage Balanced Direct Attached Cable Kit | P64689-B21 |
| Notes: When this SKU is selected, the 2nd processor and two storage controllers are required. | |
| HPE Alletra Storage Server 4140 2P 8EDSFF Rear Drive Cage Balanced Controller Attached Cable Kit | P64691-B21 |
| Notes: When this SKU is selected, the 2nd processor and two storage controllers are required. | |
| HPE Alletra Storage Server 4140 2P 8EDSFF Rear Drive Cage Direct Attached Cable Kit | P65897-B21 |
| Notes: When this SKU is selected, the 2nd processor and two storage controllers are required. | |
| HPE Alletra Storage Server 4140 1P 4SFF Rear Drive Cage 2x Controller Attached Cable Kit | P65899-B21 |
| Notes: When this SKU is selected, two storage controllers are required. | |
| HPE Alletra Storage Server 4140 1P 8EDSFF Rear Drive Cage 2x Controller Attached Cable Kit | P65901-B21 |
| Notes: When this SKU is selected, two storage controllers are required. | |
| HPE Alletra Storage Server 4140 2P 8EDSFF Rear Cage 4x Backplane 2x Drawer Controller Cable Kit | P67633-B21 |
| Notes: When this SKU is selected, the 2nd processor and four storage controllers are required. | |
| System Racking Options | SKU |
| HPE Alletra Storage Server 4140 Serial Port FIO Enablement Kit | P64208-B21 |
| HPE Alletra Storage Server 4140 Chassis Handle Kit | P79783-B21 |
| Notes: This SKU includes 4 handles and is used when installing an Alletra 4140 without the use of a server lift. Empty the Alletra 4140 enclosure (including hard drives) before lifting, installing and removing from a rack. | |
| System NVMe Boot Device Enablement Options | SKU |
| HPE Alletra Storage Server 4140 NS204i-u FIO Enablement Kit | P64210-B21 |
| Notes: – This FIO SKU is required when HPE NS204i-u Gen11 or v2 NVMe Hot Plug Boot-optimized Storage Device (P48183-B21, P81160-B21, or P81162-B21) or Alletra 41X0 NVMe M.2 Boot Device (P60350-B21) is installed. – Because this is an FIO SKU, the installation of either boot device and this enablement kit must all be done in the factory. | |
Security | |
| Description | SKU |
| HPE Bezel Lock Kit | 875519-B21 |
| Notes: This SKU is needed for each drive drawer in the Alletra 4140 to be secured. | |
HPE ProcessorsPlease select one or two matching processors. | |
| Notes: – Mixing of two different processor models is not supported. – All Processors require Heat Sink Kit (P64001-B21). | |
| Processor Option Kits | |
| 5th Generation Intel Xeon-Gold | SKU |
| Intel Xeon-Gold 6538N 2.1GHz 32-core 205W Processor Kit for HPE Alletra Storage Server 41X0 | P67412-B21 |
| Intel Xeon-Gold 6526Y 2.8GHz 16-core 195W Processor Kit for HPE Alletra Storage Server 41X0 | P67418-B21 |
| Intel Xeon-Gold 5520+ 2.2GHz 28-core 205W Processor Kit for HPE Alletra Storage Server 41X0 | P67413-B21 |
| Intel Xeon-Gold 5515+ 3.2GHz 8-core 165W Processor Kit for HPE Alletra Storage Server 41X0 | P67402-B21 |
| Intel Xeon-Gold 5512U 2.1GHz 28-core 185W Processor Kit for HPE Alletra Storage Server 41X0 | P67414-B21 |
| 5th Generation Intel Xeon-Silver | SKU |
| Intel Xeon-Gold 5512U 2.1GHz 28-core 185W Processor Kit for HPE Alletra Storage Server 41X0 | P67414-B21 |
| Intel Xeon-Silver 4516Y+ 2.2GHz 24-core 185W Processor Kit for HPE Alletra Storage Server 41X0 | P67416-B21 |
| Intel Xeon-Silver 4514Y 2.0GHz 16-core 150W Processor Kit for HPE Alletra Storage Server 41X0 | P67419-B21 |
| Intel Xeon-Silver 4510 2.4GHz 12-core 150W Processor Kit for HPE Alletra Storage Server 41X0 | P67420-B21 |
| 5th Generation Intel Xeon-Bronze | SKU |
| Intel Xeon-Bronze 3508U 2.1GHz 8-core 125W Processor Kit for HPE Alletra Storage Server 41X0 | P67404-B21 |
| Notes: U Supported in one-socket configurations only. | |
| 4th Generation Intel Xeon Gold | SKU |
| Notes: – All SKUs below ship with processor only. Adequate heatsinks (standard, or high performance) must be selected. – 4800 MT/S maximum memory speed unless otherwise noted. | |
| Intel Xeon-Gold 6438Y+ 2.0GHz 32-core 205W Processor Kit for HPE Alletra Storage Server 41X0 | P50806-B21 |
| Intel Xeon-Gold 6426Y 2.5GHz 16-core 185W Processor Kit for HPE Alletra Storage Server 41X0 | P50794-B21 |
| Intel Xeon-Gold 5420+ 2.0GHz 28-core 205W Processor Kit for HPE Alletra Storage Server 41X0 | P50804-B21 |
| Intel Xeon-Gold 5418Y 2.0GHz 24-core 185W Processor Kit for HPE Alletra Storage Server 41X0 | P50803-B21 |
| Intel Xeon-Gold 5418N 1.8GHz 24-core 165W Processor Kit for HPE Alletra Storage Server 41X0 | P50816-B21 |
| Intel Xeon-Gold 5416S 2.0GHz 16-core 150W Processor Kit for HPE Alletra Storage Server 41X0 | P50808-B21 |
| Intel Xeon-Gold 5415+ 2.9GHz 8-core 150W Processor Kit for HPE Alletra Storage Server 41X0 | P50793-B21 |
| Intel Xeon-Gold 5412U 2.1GHz 24-core 185W Processor Kit for HPE Alletra Storage Server 41X0 | P50812-B21 |
| Notes: U Supported in one-socket configurations only. | |
| 4th Generation Intel Xeon-Silver | SKU |
| Notes: – All SKUs below ship with processor only. Adequate heatsinks must be selected. – 4000 MT/s maximum memory speed unless otherwise noted. | |
| Intel Xeon-Silver 4416+ 2.0GHz 20-core 165W Processor Kit for HPE Alletra Storage Server 41X0 | P50802-B21 |
| Intel Xeon-Silver 4410Y 2.0GHz 12-core 150W Processor Kit for HPE Alletra Storage Server 41X0 | P50801-B21 |
| Midline - 6G SATA - LFF Drives | SKU |
| HPE 24TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Helium 512e ISE Multi Vendor HDD | P68585-K21 |
| HPE 20TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Helium 512e ISE Multi Vendor HDD | P53554-K21 |
| HPE 16TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Helium 512e ISE Multi Vendor HDD | P23449-K21 |
| HPE 12TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Helium 512e Multi Vendor HDD | 881787-K21 |
| HPE 8TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty 512e Multi Vendor HDD | 834028-K21 |
| HPE 4TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Multi Vendor HDD | 861683-K21 |
| HPE 2TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Multi Vendor HDD | 861681-K21 |
| HPE 1TB SATA 6G Business Critical 7.2K LFF LP 1-year Warranty Multi Vendor HDD | 861686-K21 |
SSD Selection | |
| For SSD selection guidance, please visit https://ssd.HPE.com/ For SSDs with optimal product availability, HPE advocates SSDs from the list located here: https://www.HPE.com/us/en/products.html. | |
| High Peformance Read Intensive – PCIe/NVMe EDSFF - E3S EC1 EDSFF Solid State Drives | SKU |
| HPE 3.84TB NVMe Gen5 High Performance Read Intensive E3S EC1 EDSFF SPDM PM1743 SSD | P57799-K21 |
| HPE 3.84TB NVMe Gen5 High Performance Read Intensive E3S EC1 PS1010 SSD | P70392-K21 |
| HPE 3.84TB NVMe Gen5 High Performance Read Intensive E3.S EC1 PM1753 SSD | P78789-K21 |
| HPE 7.68TB NVMe Gen5 High Performance Read Intensive E3S EC1 PS1010 SSD | P70395-K21 |
| HPE 7.68TB NVMe Gen5 High Performance Read Intensive E3.S EC1 PM1753 SSD | P78791-K21 |
| HPE 15.36TB NVMe Gen5 High Performance Read Intensive E3S EC1 PS1010 SSD | P70397-K21 |
| HPE 15.36TB NVMe Gen5 High Performance Read Intensive E3.S EC1 PM1753 SSD | P78793-K21 |
| HPE 15.36TB NVMe Gen5 High Performance Read Intensive E3S EC1 EDSFF SPDM PM1743 SSD | P57807-K21 |
| Notes: When used in the HPE Alletra Storage Server 4140, the PM1743 SSD will exhibit lower performance for some metrics compared to the values in the HPE SSD QuickSpecs. | |
| High Performance Read Intensive – PCIe/NVMe EDSFF - E3S EC1 SED FIPS 140-2 Solid State Drives | SKU |
| HPE 7.68TB NVMe Gen5 High Performance Read Intensive E3S EC1 Self-encrypting FIPS 140-3 CM7 SSD | P70674-K21 |
| HPE 15.36TB NVMe Gen5 High Performance Read Intensive E3S EC1 Self-encrypting FIPS 140-3 CM7 SSD | P79122-K21 |
| High Performance Mixed Use – PCIe/NVMe EDSFF - E3S EC1 EDSFF Solid State Drives | SKU |
| HPE 3.2TB NVMe Gen5 High Performance Mixed Use E3S EC1 PS1030 SSD | P70399-K21 |
| HPE 3.2TB NVMe Gen5 High Performance Mixed Use E3.S EC1 PM1755 SSD | P78784-K21 |
| HPE 6.4TB NVMe Gen5 High Performance Mixed Use E3.S EC1 PM1755 SSD | P78787-K21 |
| HPE 6.4TB NVMe Gen5 High Performance Mixed Use E3S EC1 PS1030 SSD | P70401-K21 |
| HPE 12.8TB NVMe Gen5 High Performance Mixed Use E3S EC1 PS1030 SSD | P70403-K21 |
| High Performance Mixed Use – PCIe/NVMe EDSFF - E3S EC1 SED FIPS 140-2 Solid State Drives | SKU |
| HPE 3.2TB NVMe Gen5 High Performance Mixed Use E3S EC1 Self-encrypting FIPS 140-3 CM7 SSD | P70669-K21 |
| HPE 6.4TB NVMe Gen5 High Performance Mixed Use E3S EC1 Self-encrypting FIPS 140-3 CM7 SSD | P70672-K21 |
| Mainstream Performance Read Intensive – PCIe/NVMe EDSFF - E3S EC1 EDSFF Solid State Drives | SKU |
| HPE 1.92TB NVMe Gen5 Mainstream Performance Read Intensive E3S EC1 CD8P SSD | P69234-K21 |
| HPE 1.92TB NVMe Gen5 Mainstream Performance Read Intensive E3S EC1 EDSFF SPDM PE1010 SSD | P77269-K21 |
| HPE 3.84TB NVMe Gen5 Mainstream Performance Read Intensive E3S EC1 CD8P SSD | P69237-K21 |
| HPE 7.68TB NVMe Gen5 Mainstream Performance Read Intensive E3S EC1 CD8P SSD | P69239-K21 |
| HPE 7.68TB NVMe Gen5 Mainstream Performance Read Intensive E3S EC1 EDSFF SPDM PE1010 SSD | P77273-K21 |
| HPE 15.36TB NVMe Gen5 Mainstream Performance Read Intensive E3S EC1 CD8P SSD | P69546-K21 |
| HPE 15.36TB NVMe Gen5 Mainstream Performance Read Intensive E3S EC1 EDSFF SPDM PE1010 SSD | P77275-K21 |
| Mainstream Performance Mixed Use – PCIe/NVMe EDSFF - E3S EC1 EDSFF Solid State Drives | SKU |
| HPE 1.6TB NVMe Gen5 Mainstream Performance Mixed Use E3S EC1 CD8P SSD | P69241-K21 |
| HPE 1.6TB NVMe Gen5 Mainstream Performance Mixed Use E3S EC1 EDSFF SPDM PE1030 SSD | P77262-K21 |
| HPE 3.2TB NVMe Gen5 Mainstream Performance Mixed Use E3S EC1 CD8P SSD | P69243-K21 |
| HPE 3.2TB NVMe Gen5 Mainstream Performance Mixed Use E3S EC1 EDSFF SPDM PE1030 SSD | P77265-K21 |
| HPE 6.4TB NVMe Gen5 Mainstream Performance Mixed Use E3S EC1 CD8P SSD | P69245-K21 |
| HPE 6.4TB NVMe Gen5 Mainstream Performance Mixed Use E3S EC1 EDSFF SPDM PE1030 SSD | P77267-K21 |
| Mainstream Performance Mixed Very Read Optimized – PCIe/NVMe EDSFF - E3S EC1 EDSFF Solid State Drives | SKU |
| HPE 3.84TB NVMe Gen4 Mainstream Performance Very Read Optimized E3S EC1 EDSFF P5430 SSD | P63930-K21 |
| HPE 7.68TB NVMe Gen4 Mainstream Performance Very Read Optimized E3S EC1 EDSFF P5430 SSD | P63934-K21 |
| HPE 15.36TB NVMe Gen4 Mainstream Performance Very Read Optimized E3S EC1 EDSFF P5430 SSD | P63938-K21 |
| HPE 30.72TB NVMe Gen4 Mainstream Performance Very Read Optimized E3S EC1 EDSFF P5430 SSD | P79065-K21 |
| Read Intensive - 24G SAS - LFF –Solid State Drives | SKU |
| HPE 7.68TB SAS 24G Read Intensive LFF LPC Multi Vendor SSD | P49040-K21 |
| Mixed Use - 12G SAS - LFF –Solid State Drives | SKU |
| HPE 960GB SAS 12G Mixed Use LFF LPC Value SAS Multi Vendor SSD | P37009-K21 |
| HPE Alletra Storage Server 4XXX 1.92TB SAS Mixed Use LFF LPC Value SAS Multi Vendor SSD | S3T31A |
| HPE Alletra Storage Server 4XXX 3.84TB SAS Mixed Use LFF LPC Value SAS Multi Vendor SSD | S3T32A |
| HPE Alletra Storage Server 4XXX 1.6TB SAS Mixed Use LFF LPC Multi Vendor SSD | S3T29A |
| HPE Alletra Storage Server 4XXX 3.2TB SAS Mixed Use LFF LPC Multi Vendor SSD | S3T30A |
| Read Intensive - 6G SATA - LFF - Solid State Drives | SKU |
| HPE 960GB SATA 6G Read Intensive LFF LPC Multi Vendor SSD | P47808-K21 |
| High Performance Read Intensive - NVMe - SFF - Solid State Drives | SKU |
| HPE 1.92TB NVMe Gen4 High Performance Read Intensive SFF BC U.3 PM1733a SSD | P50216-K21 |
| HPE 7.68TB NVMe Gen4 High Performance Read Intensive SFF BC U.3 PS1010 SSD | P70434-K21 |
| HPE 15.36TB NVMe Gen4 High Performance Read Intensive SFF BC U.3 PS1010 SSD | P70436-K21 |
| Mainstream Performance Read Intensive – NVMe – SFF – Solid State Drives | SKU |
| HPE 7.68TB NVMe Gen4 Mainstream Performance Read Intensive SFF BC U.3 SPDM 7500 SSD | P84242-K21 |
| HPE 3.84TB NVMe Gen4 Mainstream Performance Read Intensive SFF BC U.3 SPDM 7500 SSD | P84244-K21 |
| HPE 15.36TB NVMe Gen4 Mainstream Performance Read Intensive SFF BC U.3 SPDM 7500b SSD | P84239-K21 |
| High Performance Read Intensive - NVMe - SFF - Self-encrypting FIPS - Solid State Drives | SKU |
| HPE 1.92TB NVMe Gen4 High Performance Read Intensive SFF BC U.3 Self-encrypting FIPS 140-3 CM7 SSD | P61019-K21 |
| HPE 3.84TB NVMe Gen4 High Performance Read Intensive SFF BC U.3 Self-encrypting FIPS 140-3 CM7 SSD | P61027-K21 |
| HPE 7.68TB NVMe Gen4 High Performance Read Intensive SFF BC U.3 Self-encrypting FIPS 140-3 CM7 SSD | P61035-K21 |
| High Performance Mixed Use - NVMe - SFF - Solid State Drives | SKU |
| HPE 1.6TB NVMe Gen4 High Performance Mixed Use SFF BC U.3 PM1735a SSD | P50227-K21 |
| HPE 3.2TB NVMe Gen4 High Performance Mixed Use SFF BC U.3 PM1735a SSD | P50230-K21 |
| HPE 3.2TB NVMe Gen4 High Performance Mixed Use SFF BC U.3 PS1030 SSD | P70426-K21 |
| HPE 3.2TB NVMe Gen4 High Performance Mixed Use SFF BC U.3 Static PM1755 SSD | P78801-K21 |
| HPE 6.4TB NVMe Gen4 High Performance Mixed Use SFF BC U.3 PM1735a SSD | P50233-K21 |
| HPE 6.4TB NVMe Gen4 High Performance Mixed Use SFF BC U.3 PS1030 SSD | P70428-K21 |
| HPE 6.4TB NVMe Gen4 High Performance Mixed Use SFF BC U.3 Static PM1755 SSD | P78804-K21 |
| HPE 3.84TB NVMe Gen4 High Performance Read Intensive SFF BC U.3 Static PM1753 SSD | P78806-K21 |
| High Performance Mixed Use - NVMe - SFF – Self Encrypting FIPS - Solid State Drives | SKU |
| HPE 1.6TB NVMe Gen4 High Performance Mixed Use SFF BC U.3 Self-encrypting FIPS 140-3 CM7 SSD | P61043-K21 |
| HPE 3.2TB NVMe Gen4 High Performance Mixed Use SFF BC U.3 Self-encrypting FIPS 140-3 CM7 SSD | P61051-K21 |
| HPE 6.4TB NVMe Gen4 High Performance Mixed Use SFF BC U.3 Self-encrypting FIPS 140-3 CM7 SSD | P61059-K21 |
| High Performance Read Intensive - NVMe - SFF – SPDM - Solid State Drives | SKU |
| HPE 7.68TB NVMe Gen4 High Performance Read Intensive SFF BC U.3 PS1010 SSD | P70434-K21 |
| HPE 15.36TB NVMe Gen4 High Performance Read Intensive SFF BC U.3 PS1010 SSD | P70436-K21 |
| Mixed Use - NVMe - SFF - Solid State Drives | SKU |
| HPE 3.2TB NVMe Gen4 High Performance Mixed Use SFF BC U.3 PS1030 SSD | P70426-K21 |
| HPE 6.4TB NVMe Gen4 High Performance Mixed Use SFF BC U.3 PS1030 SSD | P70428-K21 |
HPE Networking | |
| 100 Gigabit PCI-e Ethernet adapters | SKU |
| Mellanox MCX623106AS-CDAT Ethernet 100Gb 2-port QSFP56 Adapter for HPE | P25960-B21 |
| Intel E810-CQDA2 Ethernet 100Gb 2-port QSFP28 Adapter for HPE | P21112-B21 |
| Notes: Only Direct Attached Cables (DAC) are supported when these SKUs are used. | |
| 25 Gigabit PCI-e Ethernet adapters | SKU |
| Broadcom BCM57504 Ethernet 10/25Gb 4-port SFP28 Adapter for HPE | P26264-B21 |
| Broadcom BCM57414 Ethernet 10/25Gb 2-port SFP28 Adapter for HPE | P26262-B21 |
| Intel E810-XXVDA2 Ethernet 10/25Gb 2-port SFP28 Adapter for HPE | P08443-B21 |
| Intel E810-XXVDA4 Ethernet 10/25Gb 4-port SFP28 Adapter for HPE | P08458-B21 |
| Mellanox MCX631102AS-ADAT Ethernet 10/25Gb 2-port SFP28 Adapter for HPE | P42044-B21 |
| 10 Gigabit PCI-e Ethernet adapters | SKU |
| Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE | P26253-B21 |
| Broadcom BCM57412 Ethernet 10Gb 2-port SFP+ Adapter for HPE | P26259-B21 |
| 1 Gigabit PCI-e Ethernet adapters | SKU |
| Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T Adapter for HPE | P51178-B21 |
| Intel I350-T4 Ethernet 1Gb 4-port BASE-T Adapter for HPE | P21106-B21 |
| Notes: – All listed PCIe NICs connected via Direct Attach Cables (DAC) are supported in both 68LFF and 92LFF chassis, with or without rear drive cage kits. – All listed PCIe 1 GbE, 10 GbE and 10/25 GbE NICs connected via Active Optical Cables (AOC) are supported in both 68LFF and 92LFF chassis, with or without rear drive cage kits. – The PCIe NIC configurations listed above applies to a maximum 30°C ambient temperature environment. | |
| OCP 3.0 Adapters | SKU |
| Intel E810-CQDA2 Ethernet 100Gb 2-port QSFP28 OCP3 Adapter for HPE | P22767-B21 |
| Intel I350-T4 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE | P08449-B21 |
| Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T OCP3 Adapter for HPE | P10097-B21 |
| Broadcom BCM57414 Ethernet 10/25Gb 2-port SFP28 OCP3 Adapter for HPE | P10115-B21 |
| Intel E810-XXVDA2 Ethernet 10/25Gb 2-port SFP28 OCP3 Adapter for HPE | P10106-B21 |
| Broadcom BCM57504 Ethernet 10/25Gb 4-port SFP28 OCP3 Adapter for HPE | P26269-B21 |
| Broadcom BCM57412 Ethernet 10Gb 2-port SFP+ OCP3 Adapter for HPE | P26256-B21 |
| Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE | P51181-B21 |
| Notes: – All listed OCP NICs connected via Direct Attach Cables (DAC) or Active Optical Cables (AOC) are supported in the 68LFF chassis, with or without rear drive cage kits. – All listed OCP NICs connected via Direct Attached Cables (DAC) are supported in the 92LFF chassis, with or without rear drive cage kits. – All listed OCP 1 GbE, 10 GbE,10/25 GbE and 100 GbE NICs connected via Active Optical Cables (AOC) are supported in the 92LFF chassis, with or without rear drive cage kits. – The OCP NIC configurations listed above applies to a maximum 30°C ambient temperature environment. | |
| Storage Offload Adapters | SKU |
| NVIDIA Ethernet 100Gb 2-port NVMe-oF Offload Adapter for HPE | R8M41A |
| Notes: Only Direct Attached Cables (DAC) are supported when these SKUs are used. | |
HPE Alletra 4140 supported configurations for Active Optical Cable (AOC) connections | ||||||
|---|---|---|---|---|---|---|
| Part Number | Networking Adapter Description | Card Form Factor | 68LFF without rear drive cage kits | 68LFF with rear drive cage kits | 92LFF without rear drive cage kits | 92LFF with rear rive cage kits |
| P08449-B21 | HPE 1 GbE 4p BASE-T I350-T4 OCP3 Adptr | OCP | 30C | 30C | 30C | 30C |
| P51181-B21 | BCM 5719 1 Gb 4p BASE-T OCP Adptr | OCP | 30C | 30C | 30C | 30C |
| P26256-B21 | HPE Eth 10 Gb 2P SFP+ BCM57412 OCP3 Adptr | OCP | 30C | 30C | 30C | 30C |
| P10097-B21 | HPE Eth 10 Gb 2P BaseT BCM57416 OCP3 Adptr | OCP | 30C | 30C | 30C | 30C |
| P10115-B21 | HPE Eth 10/25 Gb 2P 631SFP28 OCP3 Adptr | OCP | 30C | 30C | 30C | 30C |
| P10106-B21 | HPE 10/25 GbE 2P SFP28 E810 OCP3 Adptr | OCP | 30C | 30C | 30C | 30C |
| P42041-B21 | MLX MCX6314 10/25 GbE 2p SFP28 OCP3 Adptr | OCP | 30C | 30C | 30C | 30C |
| P26269-B21 | BCM 57504 10/25 GbE 4p SFP28 OCP3 Adptr | OCP | 30C | 30C | 25C | 30C |
| P22767-B21 | HPE 100 GbE 2p QSFP28 E810-CQDA2 OCP3 Adptr | OCP | 25C | 30C | 25C | 30C |
| P21106-B21 | HPE 1 GbE 4p BASE-T I350-T4 Adptr | PCIe | 30C | 30C | 30C | 30C |
| P51178-B21 | BCM 5719 1 Gb 4p BASE-T Adptr | PCIe | 30C | 30C | 30C | 30C |
| P26253-B21 | BCM 57416 10 GbE 2p BASE-T Adptr | PCIe | 30C | 30C | 30C | 30C |
| P26259-B21 | HPE Eth 10 Gb 2P SFP+ BCM57412 Adptr | PCIe | 30C | 30C | 30C | 30C |
| P26262-B21 | HPE Eth 10/25 Gb 2P SFP28 BCM57414 Adptr | PCIe | 30C | 30C | 30C | 30C |
| P08443-B21 | HPE 10/25 GbE 2P SFP28 E810 Adptr | PCIe | 30C | 30C | 30C | 30C |
| P42044-B21 | MLX MCX631102 10/25 GbE 2p SFP28 Adptr | PCIe | 30C | 30C | 30C | 30C |
| P26264-B21 | BCM 57504 10/25 GbE 4p SFP28 Adptr | PCIe | 30C | 30C | 25C | 30C |
| P08458-B21 | HPE 10/25 GbE 4p SFP28 E810-XXVDA4 Adptr | PCIe | Slot 1@25C Slot 4@20C | 25C | Slot 1@25C Slot 4@20C | 25C |
| P31246-B21 | HPE 100 GbE 1p QSFP28 MCX515A-CCAT Adptr | PCIe | Slot 1@25C Slot 4@20C | 25C | Slot 1@25C Slot 4@20C | 25C |
| P25960-B21 | HPE Eth 100G 2p MCX623106AS QSFP56 Adpt | PCIe | Slot 1@25C Slot 4@20C | 25C | Slot 1@25C Slot 4@20C | Slot 1@25C Slot 4@20C |
| P21112-B21 | HPE 100 GbE 2p QSFP28 E810-CQDA2 Adptr | PCIe | 25C | 25C | 25C | 25C |
HPE Power Supplies | |
| HPE Flexible Slot (Flex Slot) Power Supplies share a common electrical and physical design that allows for hot plug, tool-less installation into HPE ProLiant Gen10 Performance Servers. Flex Slot power supplies are certified for high-efficiency operation and offer multiple power output options, allowing users to "right-size" a power supply for specific server configurations. This flexibility helps to reduce power waste, lower overall energy costs, and avoid "trapped" power capacity in the data center. All pre-configured servers ship with a standard 6-foot IEC C-13/C-14 jumper cord (A0K02A). This jumper cord is also included with each standard AC power supply option kit. If a different power cord is required, please check the ProLiant Power Cables web page. To review the power requirements for your selected system, please use the HPE Power Advisor Tool. For information on power specifications and technical content visit HPE Server power supplies | |
HPE Flex Slot Platinum Hot-plug Power supplies | |
| SKU | |
| HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit | P03178-B21 |
| HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit | P38997-B21 |
| HPE 1800W-2200W Flex Slot Titanium Hot Plug Power Supply Kit | P44712-B21 |
| Notes: – Only supports high line voltage (200 VAC to 240 VAC). – Power supplies can only be ordered as Qty = 2 or Qty = 4. | |
| HPE 1600W Flex Slot -48VDC Hot Plug Power Supply Kit | P17023-B21 |
| HPE Alletra Storage Server 4140 3.5m DC Power Supply Cable Kit | P80006-B21 |
| Notes: P80006-21 is required when orderring HPE 1600 W Flex Slot -48 VDC Hot Plug Power Supply Kit (P17023-B21). One cable required per power supply. | |
| HPE Compute Ops Management Notes: HPE Compute Ops Management Enhanced for cloud-native management provides for management of multiple systems. Billing frequency is available as upfront payments. | |
| Description | SKU |
| HPE Compute Ops Management Standard 3-year Upfront Alletra 4000 SaaS | S1E12AAE |
| HPE Compute Ops Management Standard 5-year Upfront Alletra 4000 SaaS | S1E13AAE |
| HPE Compute Ops Management Advanced 3-year Upfront Alletra 4000 SaaS | S5E63AAE |
| HPE Compute Ops Management Advanced 5-year Upfront Alletra 4000 SaaS | S5E64AAE |
| Notes: The COM Advanced SKUs also include a iLO Advanced license and support so a standalone iLO Advanced license does not need to be ordered separately. | |
Embedded ManagementNotes: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, Hewlett Packard Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative for additional information. | |
| HPE iLO Advanced | SKU |
| HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features | 512485-B21 |
| HPE iLO Advanced AKA Tracking License with 1yr Support on iLO Licensed Features | 512487-B21 |
| HPE iLO Advanced 1-server License with 3yr Support on iLO Licensed Features | BD505A |
| HPE iLO Advanced AKA Tracking License with 3yr Support on iLO Licensed Features | BD507A |
| HPE iLO Advanced Electronic License with 1yr Support on iLO Licensed Features | E6U59ABE |
| HPE iLO Advanced Electronic License with 3yr Support on iLO Licensed Features | E6U64ABE |
| HPE iLO Common Password | SKU |
| HPE iLO Common Password FIO Setting | P08040-B21 |
| Notes: – Replaces iLO default randomized password by an HPE defined common password. HPE highly recommends changing this password immediately after the initial onboarding process. – Customers who want to choose their own custom iLO default password should use the HPE Factory Express Integration Services. | |
HPE Converged Infrastructure Management Software | |
| HPE OneView Advanced (with HPE iLO Advanced) | SKU |
| HPE OneView including 3yr 24x7 Support Flexible Quantity E-LTU | E5Y35AAE |
| HPE OneView Advanced (without HPE iLO Advanced) | SKU |
| HPE OneView w/o iLO including 3yr 24x7 Support Track 1-server LTU | P8B25A |
| HPE OneView w/o iLO including 3yr 24x7 Support Flexible Quantity E-LTU | P8B26AAE |
| Notes: − Licenses ship without media. The HPE OneView Media Kit can be ordered separately or can be downloaded at: https://www.HPE.com/us/en/integrated-systems/software.html. − Electronic and Flexible-Quantity licenses can be used to purchase multiple licenses with a single activation key. | |
HPE Security | |
| SKU | |
| HPE Bezel Lock Kit | 875519-B21 |
HPE Smart Array ControllersNotes: For more information on the HPE Gen11 Storage Controller, please refer to: | |
| Essential RAID Controllers | SKU |
| HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller | 804398-B21 |
| Notes: – This controller is used to connect external storage devices such as JBODs and tape drives to the HPE Alletra Storage Server 4140. Even though it has Gen10 in the name, it is supported in Gen11. – For more information on the HPE Smart Array E208i-p SR Gen10 Controller, please refer to the QuickSpecs. | |
| HPE Tri-Mode Controllers | SKU |
| HPE SR932i-p Gen11 x32 Lanes 8GB Wide Cache PCI SPDM Plug-in Storage Controller | P47184-B21 |
| HPE Smart Storage Battery | SKU |
| HPE 96W Smart Storage Lithium-ion Battery with 145mm Cable Kit | P01366-B21 |
| Notes: Required when more than two controllers are selected. | |
| HPE Smart Storage Hybrid Capacitor with 145mm Cable Kit | P02377-B21 |
| Notes: Required when two controllers are selected and no rear cage option is selected. | |
| HPE 16W Smart Hybrid Capacitor with 145mm Cable | P65038-B21 |
| Notes: Required when two controllers are selected and no rear cage option is selected. | |
| HPE NVMe OS Boot Device | SKU |
| HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device | P48183-B21 |
| HPE NS204i-u v2 960GB NVMe Hot Plug Boot Optimized Storage Device | P81160-B21 |
| HPE NS204i-u v2 960GB NVMe SED Hot Plug Boot Optimized Storage Device | P81162-B21 |
Optional Software | |
| SKU | |
| HPE Smart Array SR Secure Encryption (Data at Rest Encryption/per Server Entitlement) E-LTU | Q2F26AAE |
Intel VROC for HPE | |
| Intel VROC for HPE is an enterprise, hybrid RAID solution, specifically designed for NVMe SSDs connected directly to the CPU. Intel® VROC is made possible by the new CPU feature Intel® Volume Management Device, Intel® VMD, a new hardware architecture on Intel® Xeon® Scalable Processors. Intel® VMD enhances drive performance as drives are directly connect to the Intel CPU enabling the lowest latency. Intel® VROC capitalizes on Intel® VMD for a simple software RAID solution that requires no additional hardware. | |
| Description | SKU |
| Intel Virtual RAID on CPU Premium E-RTU for HPE | R7J59AAE |
| Intel Virtual RAID on CPU Premium FIO Software for HPE | R7J57A |
| Intel Virtual RAID on CPU RAID 1 E-RTU for HPE | S3Q39AAE |
| Intel Virtual RAID on CPU RAID 1 FIO Software for HPE | S3Q19A |
| Notes: For more information on features and specifications of Intel VROC for HPE see: | |
HPE Storage Options | |
| Emulex Fibre Channel HBAs | SKU |
| HPE SN1610E 32Gb 1-port Fibre Channel Host Bus Adapter | R2J62A |
| HPE SN1610E 32Gb 2-port Fibre Channel Host Bus Adapter | R2J63A |
| HPE SN1700E 64Gb 1-port Fibre Channel Host Bus Adapter | R7N77A |
| HPE SN1700E 64Gb 2-port Fibre Channel Host Bus Adapter | R7N78A |
| QLogic Fibre Channel HBAs | SKU |
| HPE SN1610Q 32Gb 1-port Fibre Channel Host Bus Adapter | R2E08A |
| HPE SN1610Q 32Gb 2-port Fibre Channel Host Bus Adapter | R2E09A |
| HPE SN1700Q 64Gb 1-port Fibre Channel Host Bus Adapter | R7N86A |
| HPE SN1700Q 64Gb 2-port Fibre Channel Host Bus Adapter | R7N87A |
HPE Racking Options | |
| Rail Kits | SKU |
| HPE Alletra Storage Server 4140 Rail Kit | P64970-B21 |
| HPE Alletra Storage Server 4140 Serial Port FIO Enablement Kit | P64208-B21 |
| HPE s6500 Chassis Handles Kit | 608477-B21 |
| Notes: SKU 608477-B21 is used when installing an HPE Alletra Storage Server 4140 in a rack and a server lift is not available. All HDDs and SSDs should be removed from server prior to lifting. The handles are removed once the server is installed. | |
HPE Racks
- – Please see the HPE Advanced Series Racks QuickSpecs for information on additional racks options and rack specifications.
- – Please see the HPE Enterprise Series Racks QuickSpecs for information on additional racks options and rack specifications.
- – Please see the HPE Standard Series Racks QuickSpecs for information on additional racks options and rack specifications.
HPE Power Distribution Units (PDUs)
- – Please see the HPE Basic Power Distribution Units (PDU) QuickSpecs for information on these products and their specifications.
- – Please see the HPE Metered Power Distribution Units (PDU) QuickSpecs for information on these products and their specifications.
- – Please see the HPE Intelligent Power Distribution Unit (PDU) QuickSpecs for information on these products and their specifications.
- – Please see the HPE Metered and Switched Power Distribution Units (PDU) QuickSpecs for information on these products and their specifications.
HPE Uninterruptible Power Systems (UPS)
To learn more, please visit the HPE Uninterruptible Power Systems (UPS) web page.
- – Please see the HPE DirectFlow Three Phase Uninterruptible Power System QuickSpecs for information on these products and their specifications.
- – Please see the HPE Line Interactive Single Phase UPS QuickSpecs for information on these products and their specifications.
Technical Specifications
System Unit
| CTO Model | 68 LFF Standard Chassis | 92 LFF Extended Chassis |
|---|---|---|
| Dimensions (Height x Width x Depth) | 175.80 x 448.00 x 860.94 mm | 175.80 x 448.00 x 1076.94 mm 6.92 x 17.64 x 42.40 in (see note below) |
| The 92LFF Extended chassis depth measurement is from the back of mounting ear to the back of chassis. Consult the HPE Alletra Storage Server 4140 Setup and Installation Guide, Mechanical Specifications section, for fitment planning. Rack fitment of HPE Alletra Storage Servers is optimized for HPE G2 Series Racks, HPE rail kits, HPE cables and HPE power distribution units. Proper rack fitment of HPE Alletra Storage Servers in third-party racks using third-party racking options is the sole responsibility of the customer. | ||
| Shipping Container Dimensions (including pallet) | 611 x 625 x 1100 mm 24 x 25 x 43 in | 594 x 625 x 1350 mm 23 x 25 x 53 in |
| Weight (approximate) | ||
| System Maximum | 117.53 kg | 147.47 kg 325.42 lb |
| Shipping Maximum | 139 kg 306 lb | 181 kg 399 lb |
| Input Requirements (per power supply) | ||
| Rated Line Voltage | 100 to 120 VAC 200 to 240 VAC | |
| BTU Rating | ||
| Maximum |
Rated line voltage: 200 to 240 VAC
Rated line voltage: 200 to 240 VAC
Rated line voltage: 100 to 120 VAC/ 200 to 240 VAC |
Rated line voltage: 200 to 240 VAC
Rated line voltage: 200 to 240 VAC
Rated line voltage: 100 to 120 VAC/ 200 to 240 VAC |
| Power Supply Output (per power supply) | ||
| Rated Steady-State Power | For 1800-2200 W Power Supply: 2200 W (at 240 VAC) For 1600 W Power Supply: 1600 W (at 240 VAC) For 1000 W Power Supply: 1000 W (at 120 or 240 VAC) | |
| Maximum Peak Power | For 1800-2200 W Power Supply: 2200 W (at 200 to 240 VAC) For 1600 W Power Supply: 1600 W (at 200 to 240 VAC) or 1000 W Power Supply: 1000 W (at 120 or 240 VAC) | |
| System Inlet Temperature | ||
| Standard Operating Support | 10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C per every 305 m (1.8°F per every 1000 ft) above sea level to a maximum of 3050 m (10,000 ft), no direct sustained sunlight. Maximum rate of change is 20°C/hr (36°F/hr). The upper limit and rate of change may be limited by the type and number of options installed. System performance during standard operating support may be reduced if operating with a fan fault or above 30°C (86°F). For approved hardware configurations, the supported system inlet range is extended to be: 5° to 10°C (41° to 50°F) and 35° to 40°C (95° to 104°F) at sea level with an altitude derating of 1.0°C per every 175 m (1.8°F per every 574 ft) above 900 m (2953 ft) to a maximum of 3050 m (10,000 ft). The approved hardware configurations for this system are listed at the URL: | |
| Relative Humidity (non-condensing) | ||
| Operating | 8% to 90% - Relative humidity (Rh), 28°C maximum wet bulb temperature, non-condensing. | |
| Non-operating | 5 to 95% relative humidity (Rh), 38.7°C (101.7°F) maximum wet bulb temperature, non-condensing | |
| Altitude | ||
| Operating | 3050 m (10,000 ft). This value may be limited by the type and number of options installed. Maximum allowable altitude change rate is 457 m/min (1500 ft/min). | |
| Non-operating | 9144 m (30,000 ft). Maximum allowable altitude change rate is 457 m/min (1500 ft/min). | |
| Acoustic Noise | ||
| Listed are the declared mean A-Weighted sound power levels (LWA,m), declared average bystander position A-Weighted sound pressure levels (LpAm) and the statistical adder for verification, Kv, a quantity to be added to the declared mean A-weighted sound power level when the product is operating in a 23°C ambient environment. Noise emissions were measured in accordance with ISO 7779 (ECMA 74) and declared in accordance with ISO 9296 (ECMA 109). The listed sound levels apply to standard shipping configurations. Additional options may result in increased sound levels. Please have your HPE representative provide information from the HPE EMESC website for further technical details regarding the configurations listed below. | ||
| Configuration SKU | Entry | Typical | Performance |
|---|---|---|---|
| Idle | |||
| LWA,m | 6.8 B | 6.8 B | 6.8 B |
| LpAm | TBD dBA | TBD dBA | TBD dBA |
| Kv | 0.4 B | 0.4 B | 0.4 B |
| Operating | |||
| LWA,m | 7.7 B | 7.4B | 7.3 B |
| LpAm | 62 dBA | 59 dBA | 61 dBA |
| Kv | 0.4 B | 0.4 B | 0.4 B |
| Notes: Acoustic levels presented here are generated by the test configuration only. Acoustic levels will vary depending on system configuration. Values are subject to change without notification and are for reference only. | |||
Emissions Classification (EMC)
To view the regulatory information for your product, view the Safety and Compliance Information for Server, Storage, Power, Networking, and Rack Products, available at the Hewlett Packard Enterprise Support Center:
http://www.HPE.com/support/Safety-Compliance-EnterpriseProducts
Environment-friendly Products and Approach - End-of-life Management and Recycling
Hewlett Packard Enterprise offers end-of-life product return, trade-in, and recycling programs, in many geographic areas, for our products. Products returned to Hewlett Packard Enterprise will be recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard Enterprise web site. These instructions may be used by recyclers and other WEEE treatment facilities as well as Hewlett Packard Enterprise OEM customers who integrate and re-sell Hewlett Packard Enterprise equipment.
TCO Certified
The HPE Alletra Storage Server 4140 has been TCO Certified. All HPE TCO Certified products can be found on:
TCO Certified Product Finder. More information on TCO Certified can be downloaded here: https://www.HPE.com/us/en/about/environment/eco-labels.html
Summary of Changes
| Date | Version History | Action | Description of Change |
|---|---|---|---|
| 03-Aug-2026 | Updated the Operating Systems and Virtualization Software section with newly supported operating systems and hypervisors, including Windows Server 2025, RHEL 10.0, SLES 16, VMware 9.0 and VMware 9.1 | ||
| Added |
New SKUs added - P78789-K21, P78791-K21, P78793-K21 | ||
| Removed | Obsolete or not supported SKUs removed - P50219-K21, P50222-K21 | ||
| 04-May-2026 | Changed | Minor wording and format updates were performed. | |
| 06-Apr-2026 | Changed | Configuration Information and Core Options sections were updated. Main changes:
| |
| Added | New SKUs added - P78784-K21, P78787-K21, P78801-K21, P78804-K21, P78806-K21 | ||
| 02-Mar-2026 | Added | Added new Smart Array option: HPE 16W Smart Hybrid Capacitor with 145 mm Cable (SKU: P65038‑B21), including usage note for configurations with two controllers and no rear cage option. | |
| Removed | Obsolete boot‑optimized storage devices removed, including: HPE 480 GB, 960 GB, and 1.92 TB NVMe Gen3 Mainstream Performance Read Intensive M.2 SSDs (SKUs: P40513‑B21, P40514‑B21, P40515‑B21). Obsolete HDD options removed from the HPE Drives section, including: – 18 TB, 10 TB, 6 TB, and 2 TB SAS HDDs. – 6 TB SATA HDD. (SKUs: P37669‑K21, P53556‑K21, 861746‑K21, 833926‑K21, 861742‑K21). Obsolete SSD removed from SSD Selection: – HPE 7.68 TB NVMe Gen5 High Performance Read Intensive E3S EC1 EDSFF SPDM PM1743 SSD (SKU: P57803‑K21). InfiniBand section removed, including adapter, SKU, and notes related to the HPE InfiniBand HDR100/Ethernet 100Gb 2‑port QSFP56 PCIe4 x16 Adapter (SKU: P23666‑B21). | ||
| 05-Jan-2026 | Changed | Updated multiple sections for clarity and consistency. Revised processor, memory, boot device, drive, SSD, networking, InfiniBand, power supply, and Smart Array controller option descriptions to align with HPE naming standards and editorial guidelines. | |
| 01-Dec-2025 | Added | New Smart Array Controller option added: HPE 16 W Smart Hybrid Capacitor (SKU: P65038-B21). | |
| Removed | Obsolete drive removed: HPE 10 TB SATA 6G Business Critical HDD (SKU: P53557-K21). | ||
| 10-Nov-2025 | Added | New SKU was added under High Performance Read Intensive - NVMe - SFF - Solid State Drives: P84239-K21 | |
| 13-Oct-2025 | Changed | Two new boot-optimized storage devices were added to the Overview section. | |
| Added | P81160-B21, P81162-B21 | ||
| Removed | P77050-K21, P77053-K21, P77055-K21, P77057-K21, P77059-K21, P77061-K21, P78914-K21, P78917-K21, P78919-K21, P78921-K21, P77271-K21, P79965-K21, P79618-K21. – Obsolete SKUs removed - P23664-B21, P31324-B21 | ||
| 18-Aug-2025 | Changed | Standard Features section was updated – Windows Server 2025 was added as Operating System / Virtualization System available. Additional Options section was updated – HPE Alletra 4140 supported configurations for Active Optical Cable (AOC) connections information was updated. | |
| 04-Aug-2025 | Changed | Additional Options section was updated | |
| 28-Jul-2025 | Changed | Survey link updated | |
| 05-May-2025 | Changed | Core Options section was updated Obsolete SKU removed - E5Y34A / P8B24A | |
| 07-Apr-2025 | Changed | Overview, Standard Features Configuration Information and Core Options and Additional Options sections were updated | |
| 03-Feb-2025 | Changed | Core Options section was updated Obsolete SKU removed - P37678-K21 | |
| 06-Jan-2025 | Changed | Core Options section was updated Obsolete SKU removed - P31246-B21 | |
| 18-Nov-2024 | Changed | Core Options and Additional Options sections were updated | |
| 04-Nov-2024 | Changed | Obsolete SKU removed - P56585-K21 | |
| 07-Oct-2024 | Changed | Overview, Standard Features Configuration Information and Core Options sections were updated | |
| 03-Sep-2024 | Changed | Overview, Standard Features Configuration Information and Core Options sections were updated | |
| 05-Aug-2024 | Changed | Configuration Information and Core Options sections were updated | |
| 01-Jul-2024 | Changed | Core Options section was updated | |
| 20-May-2024 | Changed | Configuration Information and Core Options sections were updated | |
| 06-May-2024 | Changed | Overview, Standard Features Configuration Information and Core Options sections were updated Obsolete SKUs removed | |
| 18-Mar-2024 | Changed | Configuration Information and Core Options sections were updated | |
| 04-Mar-2024 | Changed | Overview and Core Options sections were updated | |
| 08-Jan-2024 | Changed | Overview, Standard Features and Configuration Information sections were updated | |
| 04-Dec-2023 | New | New QuickSpecs |
© Copyright 2026 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
Intel® and Xeon® are registered trademarks of Intel Corporation in the U.S. and other countries.
Microsoft®, Windows®, and Windows Server® are U.S. registered trademarks of the Microsoft group of companies.
For hard drives, 1 GB = 1 billion bytes. Actual formatted capacity is less due to system requirements
a50007017enw, - 17127 - Worldwide - V27 - 03-August-2026
