HPE G2 Advanced Series Racks QuickSpecs
Table of Contents
HPE G2 Advanced Series Racks are designed for low-to-medium density IT configurations deployed in a diverse set of environments – from the data closet to the data center.
Following EIA-310 specifications for 19-inch racks, G2 Advanced Racks are designed specifically to support a wide range of HPE IT equipment (servers, storage, and networking), as well as the entire portfolio HPE Rack and Power Infrastructure solutions (PDU, UPS and KVM).
Overview
All HPE G2 Advanced Series Racks are supported with a 10-year limited warranty that provides either repair or complete replacement of the rack. Offering this industry-leading warranty requires a highly reliable and durable design that includes features such as a fully welded, roll-form rack design, heavy-gauge rails, and heavy-duty casters that can support a static load of up to 3,000 lbs. Additionally, select shock pallet models include packaging specifically designed to support the shipment of pre-configured racks with up to 2,250 lbs. of It equipment.
The G2 Advanced Series Rack portfolio includes a wide range of rack models covering a variety of heights, widths, and depths. To simplify purchasing and installation, all rack models include locking side panels and baying kits. Additionally, HPE offers a large portfolio of rack accessories that support airflow management, cable management, and added rack stability.
![[IMAGE1]](https://assets.ext.hpe.com/is/image/hpedam/c05324689_block1img?$crimg$ "[IMAGE1]")
![[IMAGE2]](https://assets.ext.hpe.com/is/image/hpedam/c05324689_block1img2?$crimg$ "[IMAGE2]")
![[IMAGE3]](https://assets.ext.hpe.com/is/image/hpedam/c05324689_block1img3?$crimg$ "[IMAGE3]")
P9K07A
![[IMAGE4]](https://assets.ext.hpe.com/is/image/hpedam/c05324689_block1img4?$crimg$ "[IMAGE4]")
P9K09A
Standard Features
HPE G2 Advanced Series Rack Models
Review the following details to better understand the different rack models that are offered in the HPE G2 Advanced Series rack portfolio.
Pallet Rack
Standard pallet and packaging for racks that will be configured on-site.
Shock Pallet
Pallet and packaging designed to support racks that will be shipped directly to the data center fully configured.
- − Can support up to 2,250 lbs. of IT equipment during shipment
- − Packaging includes integrated ramp to simplify rack deployment
- − Must be selected when requesting HPE Factory Express Services
Network Racks
Designed to support dense Networking equipment configurations, or the integration of Networking, Server, and Storage equipment into a single industry standard 19” rack.
- − Front and rear vertical EIA rails are moved back 75 mm to facilitate front to rear cabling
- − Include additional bristle covered cable access slots in the front and top of the rack to prevent the mixing of hot and cold air and to allow pass-through for large cable connectors and bundles
HPE G2 Advanced Series Racks | |
| 600mm Wide G2 Advanced Series Rack Models | |
| HPE 22U 600mmx1075mm G2 Kitted Advanced Pallet Rack with Side Panels and Baying | P9K03A |
| HPE 22U 600mmx1075mm G2 Kitted Advanced Shock Rack with Side Panels and Baying | P9K04A |
| HPE 42U 600mmx1075mm G2 Kitted Advanced Pallet Rack with Side Panels and Baying | P9K07A |
| HPE 42U 600mmx1075mm G2 Kitted Advanced Shock Rack with Side Panels and Baying | P9K08A |
| Additional HPE G2 Advanced Series Rack models | |
| 600mm Wide G2 Advanced Series Rack Models | |
| HPE 36U 600mmx1075mm G2 Kitted Advanced Pallet Rack with Side Panels and Baying | P9K05A |
| HPE 36U 600mmx1075mm G2 Kitted Advanced Shock Rack with Side Panels and Baying | P9K06A |
| HPE 42U 600mmx1200mm G2 Kitted Advanced Pallet Rack with Side Panels and Baying | P9K09A |
| HPE 42U 600mmx1200mm G2 Kitted Advanced Shock Rack with Side Panels and Baying | P9K10A |
| 800mm Wide G2 Advanced Series Rack Models | |
| HPE 42U 800mmx1200mm G2 Kitted Advanced Pallet Rack with Side Panels and Baying | P9K15A |
| G2 Advanced Series Network Rack Models | |
| | |||||||
|---|---|---|---|---|---|---|---|
| 600mm Wide G2 Advanced Series Rack Models | | ||||||
| Model | Rack Height | Rack Weight (without packaging) | Shipping Weight (with packaging) | Static Load (without packaging) | Dynamic Load (Rolling without packaging) | Dynamic Load (Shipping) | |
| P9K03A | 22U | 173.06 lb (78.50 kg) | 202.83 lb (92.00 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | _ | |
| P9K04A | 22U | 173.06 lb (78.50 kg) | 376.99 lb (171.00 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | 2250 lb (1020.56 kg) | |
| P9K07A | 42U | 281.09 lb (127.50 kg) | 310.85 lb (141.00 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | _ | |
| P9K08A | 42U | 281.09 lb (127.50 kg) | 485.02 lb (220.00 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | 2250 lb (1020.56 kg) | |
| P9K05A | 36U | 255.74 lb (116.00 kg) | 285.50 lb (129.50 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | _ | |
| P9K06A | 36U | 255.74 lb (116.00 kg) | 459.66 lb (208.50 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | 2250 lb (1020.56 kg) | |
| P9K09A | 42U | 310.85 lb (141.00 kg) | 342.802 lb (155.50 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | _ | |
| P9K10A | 42U | 310.85 lb (141.00 kg) | 531.31 lb (241.00 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | 2250 lb (1020.56 kg) | |
| P9K19A | 48U | 141.50 lb (311.95 kg) | 341.72 lb (155.00 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | _ | |
| | |||||||
|---|---|---|---|---|---|---|---|
| 800mm Wide G2 Advanced Series Rack Models- | | ||||||
| Model | Rack Height | Rack Weight (without packaging) | Shipping Weight (with packaging) | Static Load (without packaging) | Dynamic Load (Rolling without packaging) | Dynamic Load (Shipping) | |
| P9K11A | 42U | 346.35 lb (157.10 kg) | 376.11 lb (170.60 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | _ | |
| P9K12A | 42U | 346.35 lb (157.10 kg) | 550.27 lb (249.60 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | 2250 lb (1020.56 kg) | |
| P9K15A | 42U | 362.66 lb (164.50 kg) | 394.63 lb (179.00 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | _ | |
| P9K16A | 42U | 362.66 lb (164.50 kg) | 583.12 lb (264.50 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | 2250 lb (1020.56 kg) | |
| P9K21A | 48U | 363.76 lb (165.00 kg) | 393.53 lb (178.50 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | 2250 lb (1020.56 kg) | |
| | |||||||
|---|---|---|---|---|---|---|---|
| G2 Advanced Series Network Rack Models | | ||||||
| Model | Rack Height | Rack Weight (without packaging) | Shipping Weight (with packaging) | Static Load (without packaging) | Dynamic Load (Rolling without packaging) | Dynamic Load (Shipping) | |
| P9K17A | 42U | 346.35 lb (157.10 kg) | 376.11 lb (170.60 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | _ | |
| P9K18A | 42U | 362.66 lb (164.50 kg) | 583.12 lb (264.50 kg) | 3,000 lb (1,360.78 kg) | 2500 lb (1133.98 kg) | 2250 lb (1020.56 kg) | |
What’s Included With Rack?
- – Complete set of 4-piece lockinWhat’s Included With Rack?
- – Complete set of 4-piece locking side panels
- – Baying kit
- – Hardware Kit (including key to front and rear doors)
- – Support documentation
Compatibility
- – Designed to EIA-310 specifications for industry standard racks
- – Designed for HPE IT solutions
- – Integration with HPE rack and power infrastructure solutions
- – Include adjustable EIA rails
Reliability/Durability
- – 10-year limited warranty. Hardware replacement and repair is available for ten years from date of purchase.
- – Proven frame design, heavy-gauge mounting rails, and heavy-duty casters can support up to 3,000 lbs. static loads and up to 2,250 lbs. dynamic (rolling) loads
- – Highest levels of ship-load testing to ensure a dynamic load of up to 2,250 lbs. when selecting a shock pallet rack option
- – Fully welded, roll form rack frame
- – High-strength steel side bracing
Usability/Management
- – Industry's widest range of enclosure sizes with rack depths of 42-inches or greater
- – Side panels and baying kit included with all G2 Advanced Series rack models
- – Multiple 800mm wide rack models including Network rack models available
- – Includes either 2 (1,075 mm models) or 4 (1,200 mm models) integrated and adjustable full-height PDU Mounting Trays in each rack to support PDU and cable management accessories
- – 80% front-door airflow perforation
- – Removal and reversible rack canopy with pre-installed brush strips capable of supporting easy pass-through of large cables and connectors
- – Enhanced front and rear door cabling channelsg side panels
- – Baying kit
- – Hardware Kit (including key to front and rear doors)
- – Support documentation
- – Redesigned bottom area designed for unobstructed access to data center floor
- – Depth adjustable, side EIA mounting rails designed to support front-to-back cabling
- – Flush-mounted, locking 2-piece side panels
- – Quick release front and rear doors
- – Wide array of rack accessories for airflow management, cable management, stabilization, and safety/security
- – Eyebolt support integrated into enclosure frame
- – Configuration services through HPE Factory Express
Safety/Security
- – Industry standard lock panel on the front and rear doors capable of supporting a wide range of third-party electronic locking/security solutions
- – Flush-mounted side panels that support rack baying when installed
- – Optional electrical grounding covering frame and components
- – Single key access for front doors, rear doors, and side panels
Industry Standards Compliance
- – EIA
- – Type A cabinet per section 4.1.1
- – UL/CES Certification
- – Yes
- – WEEE
- – Yes
- – RoHS compliant
- – Yes
- – TAA compliant
- – Compliant for all rack models sold in North America
- – Depth adjustable, side EIA mounting rails designed to support front-to-back cabling
- – Flush-mounted, locking 2-piece side panels
- – Quick release front and rear doors
- – Wide array of rack accessories for airflow management, cable management, stabilization, and safety/security
- – Eyebolt support integrated into enclosure frame
- – Configuration services through HPE Factory Express
Service and Support
HPE Services
No matter where you are in your digital transformation journey, you can count on HPE Services to deliver the expertise you need when, where and how you need it. From planning to deployment, ongoing operations and beyond, our experts can help you realize your digital ambitions.
Consulting Services
No matter where you are in your journey to hybrid cloud, experts can help you map out your next steps. From determining what workloads should live where, to handling governance and compliance, to managing costs, our experts can help you optimize your operations.
https://www.hpe.com/services/consulting
HPE Managed Services
HPE runs your IT operations, providing services that monitor, operate, and optimize your infrastructure and applications, delivered consistently and globally to give you unified control and let you focus on innovation.
Operational Services
Optimize your entire IT environment and drive innovation. Manage day-to-day IT operational tasks while freeing up valuable time and resources. Meet service-level targets and business objectives with features designed to drive better business outcomes.
https://www.hpe.com/services/operational
HPE Complete Care Service
HPE Complete Care Service is a modular, edge-to-cloud IT environment service designed to help optimize your entire IT environment and achieve agreed upon IT outcomes and business goals through a personalized experience. All delivered by an assigned team of HPE Services experts. HPE Complete Care Service provides:
- − A complete coverage approach – edge to cloud
- − An assigned HPE team
- − Modular and fully personalized engagement
- − Enhanced Incident Management experience with priority access
- − Digitally enabled and AI-driven customer experience
HPE Tech Care Service
HPE Tech Care Service is the operational support service experience for HPE products. The service goes beyond traditional support by providing access to product specific experts, an AI-driven digital experience, and general technical guidance to not only reduce risk but constantly search for ways to do things better. HPE Tech Care Service delivers a customer-centric, AI-driven, and digitally enabled customer experience to move your business forward. HPE Tech Care Service is available in three response levels. Basic, which provides 9x5 business hour availability and a 2-hour response time. Essential which provides a 15-minute response time 24x7 for most enterprise level customers, and Critical which includes a 6-hour repair commitment where available and outage management response for severity 1 incidents.
https://www.hpe.com/services/techcare
HPE Lifecycle Services
HPE Lifecycle Services provide a variety of options to help maintain your HPE systems and solutions at all stages of the product lifecycle. A few popular examples include:
Lifecycle Install and Startup Services: Various levels for physical installation and power on, remote access setup, installation and startup, and enhanced installation services with the operating system.
- − HPE Firmware Update Analysis Service: Recommendations for firmware revision levels for selected HPE products, taking into account the relevant revision dependencies within your IT environment.
- − HPE Firmware Update Implementation Service: Implementation of firmware updates for selected HPE server, storage, and solution products, taking into account the relevant revision dependencies within your IT environment.
- − Implementation assistance services: Highly trained technical service specialists to assist you with a variety of activities, ranging from design, implementation, and platform deployment to consolidation, migration, project management, and onsite technical forums.
- − HPE Service Credits: Access to prepaid services for flexibility to choose from a variety of specialized service activities, including assessments, performance maintenance reviews, firmware management, professional services, and operational best practices.
Notes: To review the list of Lifecycle Services available for your product go to: https://www.hpe.com/services/lifecycle
For a list of the most frequently purchased services using service credits, see the HPE Service Credits Menu
Other Related Services from HPE Services:
HPE Education Services
Training and certification designed for IT and business professionals across all industries. Broad catalogue of course offerings to expand skills and proficiencies in topics ranging from cloud and cybersecurity to AI and DevOps. Create learning paths to expand proficiency in a specific subject. Schedule training in a way that works best for your business with flexible continuous learning options.
https://www.hpe.com/services/training
Defective Media Retention
An option available with HPE Complete Care Service and HPE Tech Care Service and applies only to Disk or eligible SSD/Flash Drives replaced by HPE due to malfunction.
Consult your HPE Sales Representative or Authorized Channel Partner of choice for any additional questions and services options.
Parts and Materials
HPE will provide HPE-supported replacement parts and materials necessary to maintain the covered hardware product in operating condition, including parts and materials for available and recommended engineering improvements.
Parts and components that have reached their maximum supported lifetime and/or the maximum usage limitations as set forth in the manufacturer's operating manual, product quick-specs, or the technical product data sheet will not be provided, repaired, or replaced as part of these services.
How to Purchase Services
Services are sold by Hewlett Packard Enterprise and Hewlett Packard Enterprise Authorized Service Partners:
- − Services for customers purchasing from HPE or an enterprise reseller are quoted using HPE order configuration tools.
- − Customers purchasing from a commercial reseller can find services at https://ssc.hpe.com/portal/site/ssc/
AI Powered and Digitally Enabled Support Experience
Achieve faster time to resolution with access to product-specific resources and expertise through a digital and data driven customer experience
Sign into the HPE Support Center experience, featuring streamlined self-serve case creation and management capabilities with inline knowledge recommendations. You will also find personalized task alerts and powerful troubleshooting support through an intelligent virtual agent with seamless transition when needed to a live support agent.
Consume IT On Your Terms
HPE GreenLake edge-to-cloud platform brings the cloud experience directly to your apps and data wherever they are—the edge, colocations, or your data center. It delivers cloud services for on-premises IT infrastructure specifically tailored to your most demanding workloads. With a pay-per-use, scalable, point-and-click self-service experience that is managed for you, HPE GreenLake edge-to-cloud platform accelerates digital transformation in a distributed, edge-to-cloud world.
- − Get faster time to market
- − Save on TCO, align costs to business
- − Scale quickly, meet unpredictable demand
- − Simplify IT operations across your data centers and clouds
To learn more about HPE Services, please contact your Hewlett Packard Enterprise sales representative or Hewlett Packard Enterprise Authorized Channel Partner. Contact information for a representative in your area can be found at "Contact HPE" https://www.hpe.com/us/en/contact-hpe.html
For more information
Related Options
| Hewlett Packard Enterprise offers a full line of accessories and options that can be added to HPE Racks allowing you to customize each rack to fit your IT requirements. HPE Rack accessories include upgrades such as side panels, baying kits, cable management kits, drawers, shelving, and filler panels. To build a complete rack and power infrastructure for your IT environment, Hewlett Packard Enterprise also offers a full line of options that include power distribution units (PDU), uninterruptible power systems (UPS), and KVM (keyboard, video, mouse) consoles and switches. See HPE Rack and Power Infrastructure for more complete information at: https://www.hpe.com/info/rackandpower. Notes:0D1 may appear after the above selected part numbers on your sales order if factory integration is indicated. | |
Rack Baying Kits | |
| HPE G2 Rack Baying Kit | P9L12A |
| Notes: This Baying Kit is used to connect HPE G2 racks of the same U height and depth together and includes the following components: (4) 24-inch baying brackets, (4) 600mm baying brackets, and T-30 Torx screws. | |
| HPE G2 Advanced and Enterprise Series Rack 1075mm and 1200mm Offset Baying Kit | P9L19A |
Airflow Optimization | |
| HPE Air Flow Optimization Kit | BW930A |
| Notes: – The Airflow Optimization kit seals air gaps inside the rack, in between bayed racks, and the clearance from the floor to the rack to prevent hot and cold air from mixing thus optimizing the temperature at which the chilled air enters the racked servers. – When configuring racks through Factory Express, a Rack Optimization kit will automatically ship with the rack. This kit is recommended for all other bayed rack configurations also. | |
Sidewall Panel Kits | |
| HPE G2 Rack 42U 1075mm Side Panel Kit | P9L15A |
| HPE G2 Rack 42U 1200mm Side Panel Kit | P9L16A |
| HPE G2 Rack 48U 1075mm Side Panel Kit | P9L17A |
| HPE G2 Rack 48U 1200mm Side Panel Kit | P9L18A |
| Notes: – HPE G2 Rack Side Panel Kits are locking, 2-piece panels that provide coverage for both sides of the rack. – All HPE G2 Advanced Series Racks ship with a complete set of side panels. | |
Rack Stabilization Kits | |
| HPE 600mm Rack Stabilizer Kit | BW932A |
| HPE 600mm Heavy Duty V2 Stabilizer Kit | BW961A |
| HPE 800mm Rack Stabilizer Kit | BW933A |
| Notes: Anti-tip stabilizer kits provide stability and support when equipment is installed, removed or accessed within the rack. Heavy Duty stabilizer kits should be used when a single racked component exceeds 200 lbs. | |
| HPE Rack Ballast Kit | 120672-B21 |
| Notes: The Ballast Kit is designed to provide additional stability and support when used with the Stabilizer Kit. It is typically used when very heavy equipment is routinely installed, removed or accessed within the rack. Compatible with HPE Advanced and Enterprise Series racks. | |
Tie Down Kit | |
| HPE Universal G2 Rack Tie Down Kit | Q9V01A |
| Notes: The Rack Tie Down Kit is used to secure the rack to the datacenter floor. | |
Universal 1U Filler Panels | |
| HPE 1U 10-pack Black Universal Filler Panel | BW928A |
| HPE 1U 100-pack Black Universal Filler Panel | BW929A |
| Notes: Blanking panels are made from high grade molded plastic and are designed to be installed without tools. The use of blanking panels is recommended to ensure proper airflow. | |
Rack Shelves | |
| HPE 10000 Rack 1U Monitor Utility Shelf (Recommended) | 253449-B21 |
| Notes: This is a 1U fixed shelf that can be mounted at any height to place a monitor or other component within the rack. The shelf has a maximum weight capacity of 150 lbs. (68 kg). | |
Adjustable Rails | |
| Depth Adjustable Fixed Rail Kit | 332558-B21 |
| Notes: This kit contains two depth adjustable rails that allow Hewlett Packard Enterprise servers, storage, UPSs and other products to be mounted in HPE or third-party racks. Maximum weight capacity is 300 lbs. (136 kg). | |
Locking Drawer | |
| HPE 2U Universal Locking Drawer (Extended) | 361591-B21 |
| Notes: This rack accessory mounts on HPE Advanced and Enterprise Series racks with sliding rails and is used to store CD's, instruction manuals, tools, and any other items that are frequently used at the rack. Drawer includes lock. | |
Cable Management Kits | |
| HPE Quarter Turn Hook and Loop 10 Pack Kit | BW963A |
| HPE Quarter Turn Hook and Loop 100 Pack Kit | BW964A |
| Notes: Quarter turn hook and loop straps help attach cables and other devices to the accessory bracket in the rear of the rack without tools. | |
| HPE G2 Cable Management D-ring Kit | Q9V02A |
| Notes: This kit consists of 10 "D" rings that can be used for cable management. | |
| HPE Rack Cable Management Velcro Clips | 379820-B21 |
| HPE G2 Rack Cable Management Combo Kit | Q9V03A |
| Notes: The HPE Rack Cable Management Kit includes a 1U and 2U front cable entry panel with brush inserts, 2x crossover cable brackets, 10x D-rings, 10x hook and loop straps (8 inch), 10x hook and loop straps (10 inch), and mounting hardware. | |
Grounding Kit | |
| HPE G2 Rack Grounding Kit | P9L11A |
| Notes: The Rack Grounding Kit can be used to reduce the level of electromagnetic emissions outside the rack. The Kit includes (2) 6” Grounding Straps, (3) 14.5” Grounding Straps, (4) 6” Grounding Straps w/connectors, (4) 14.5” Grounding Straps w/connectors. | |
Hardware Kit | |
| HPE Rack Hardware Kit | H6J85A |
| Notes: The HPE Rack Hardware Kit includes 24x M6 cage nuts, 24x M6x16 T25 screws, 10x 6mm thread clip nuts, cage nut tool, and 5x Quarter turn hook and loop straps. | |
HPE Support Services | |
| HPE Install Rack and Rack Options Service | U2871E |
HPE Factory Express Services | |
| HPE Hardware Customization Service | HA838A1 |
| HPE 3rd Party Hardware Install Service | HA844A1 |
| HPE Customer Defined Rack Cable Labeling Service | HA850A1 |
| HPE Customer Furnished Equipment Handling Service | HA851A1 |
| HPE Rack Product Placement Service | HA864A1 |
| Notes: HPE Factory Express offers a full line of services. For more information visit http://www.hpe.com/info/factoryexpress. | |
Technical Specifications
| HPE G2 Advanced Series Racks | |||||
|---|---|---|---|---|---|
| 600mm Wide G2 Advanced Series Rack Models | |||||
| Rackable/Useable Area | Total Area | ||||
| Model | Height | Width | Depth | Total Cabinet Area (HxWxD) | Shipping Dimensions (HxWxD) |
| P9K03A | 22U | 600 mm | 1075 mm | 43.95 x 23.50 x 43.78 in 1116.38 x 597.00 x 1111.43 mm | 51 x 28 x 48 in 1282 x 710 x 1200 mm |
| P9K04A | 22U | 600 mm | 1075 mm | 43.95 x 23.50 x 43.78 in 1116.38 x 597.00 x 1111.43 mm | 60 x 36 x 51 in 1518 x 903 x 1291 mm |
| P9K07A | 42U | 600 mm | 1075 mm | 78.99 x 23.50 x 43.78 in 2006.39 x 597.00 x 1111.43 mm | 86 x 28 x 48 in 2172 x 710 x 1200 mm |
| P9K08A | 42U | 600 mm | 1075 mm | 78.99 x 23.50 x 43.78 in 2006.39 x 597.00 x 1111.43 mm | 86 x 36 x 51 in 2184 x 903 x 1291 mm |
| P9K05A | 36U | 600 mm | 1075 mm | 68.83 x 23.50 x 43.78 in 1748.38 x 597.00 x 1111.43 mm | 76 x 28 x 48 in 1914 x 710 x 1200 mm |
| P9K06A | 36U | 600 mm | 1075 mm | 68.83 x 23.50 x 43.78 in 1748.38 x 597.00 x 1111.43 mm | 86 x 36 x 51 in 2184 x 903 x 1291 mm |
| P9K09A | 42U | 600 mm | 1200 mm | 78.99 x 23.50 x 50.65 in 2006.39 x 597.00 x 1286.43 mm | 86 x 28 x 55 in 2167 x 710 x 1393 mm |
| P9K10A | 42U | 600 mm | 1200 mm | 78.99 x 23.50 x 50.65 in 2006.39 x 597.00 x 1286.43 mm | 86 x 36 x 58 in 2185 x 903 x 1470 mm |
| P9K19A | 48U | 600 mm | 1075 mm | 90.49 x 23.50 x 43.78 in 2298.41 x 597.00 x 1111.43 mm | 96 x 28 x 48 in 2437 x 710 x 1200 mm |
| HPE G2 Advanced Series Racks | |||||
|---|---|---|---|---|---|
| 800mm Wide G2 Advanced Series Rack Models | |||||
| Rackable/Useable Area | Total Area | ||||
| Model | Height | Width | Depth | Total Cabinet Area (HxWxD) | Shipping Dimensions (HxWxD) |
| P9K11A | 42U | 800 mm | 1075 mm | 78.99 x 31.38 x 43.78 in 2006.39 x 797.00 x 1111.43 mm | 76 x 36 x 48 in 2172 x 910 x 1218 mm |
| P9K12A | 42U | 800 mm | 1075 mm | 78.99 x 31.38 x 43.78 in 2006.39 x 797.00 x 1111.43 mm | 87 x 44 x 51 in 2193 x 1103 x 1291 mm |
| P9K15A | 42U | 800 mm | 1200 mm | 78.99 x 31.38 x 50.65 in 2006.39 x 797.00 x 1286.43 mm | 76 x 36 x 55 in 2172 x 910 x 1393 mm |
| P9K16A | 42U | 800 mm | 1200 mm | 78.99 x 31.38 x 50.65 in 2006.39 x 797.00 x 1286.43 mm | 88 x 44 x 58 in 2216 x 1103 x 1470 mm |
| P9K21A | 48U | 800 mm | 1075 mm | 90.49 x 31.38 x 43.78 in 2298.41 x 797.00 x 1111.43 mm | 96 x 36 x 48 in 2438 x 910 x 1218 mm |
| HPE G2 Advanced Series Racks | |||||
|---|---|---|---|---|---|
| G2 Advanced Series Network Rack Models | |||||
| Rackable/Useable Area | Total Area | ||||
| Model | Height | Width | Depth | Total Cabinet Area (HxWxD) | Shipping Dimensions (HxWxD) |
| P9K17A | 42U | 800 mm | 1075 mm | 78.99 x 31.38 x 43.78 in 2006.39 x 797.00 x 1111.43 mm | 76 x 36 x 48 in 2172 x 910 x 1218 mm |
| P9K18A | 42U | 800 mm | 1200 mm | 78.99 x 31.38 x 50.65 in 2006.39 x 797.00 x 1286.43 mm | 88 x 44 x 58 in 2216 x 1103 x 1470 mm |
Understanding rack weights and loads
HPE G2 Advanced Series Racks are designed to support high-capacity weight loads that include the weight of the rack and all the equipment installed. Weight loads are defined as:
- − Shipping Weight - rack including shipping packaging and materials.
- − Static Load – maximum loaded weight that a rack can support when stationary.
- − Dynamic Load (Rolling) – maximum loaded weight a rack can support when rolled.
- − Dynamic Load (Shipping) – maximum loaded weight a rack can support when shipped configured with IT equipment
HPE G2 Advanced Series Racks are rated for Static Loads of up to 3,000 lbs. If you require a rack that can be shipped when fully loaded with equipment, please consider purchasing one of our Shock Pallet models that can support up to 2,250 lbs. during shipment.
Environment-friendly Products and Approach - End-of-life Management and Recycling
Hewlett Packard Enterprise offers end-of-life product return, trade-in, and recycling programs, in many geographic areas, for our products. Products returned to Hewlett Packard Enterprise will be recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard Enterprise web site. These instructions may be used by recyclers and other WEEE treatment facilities as well as Hewlett Packard Enterprise OEM customers who integrate and re-sell Hewlett Packard Enterprise equipment.
Summary of Changes
| Date | Version History | Action | Description of Change |
|---|---|---|---|
| 16-Feb-2026 | Changed | New branding applied to document | |
| 04-Dec-2023 | Changed | Service and Support Section was updated. | |
| 15-Nov-2021 | Changed | Service and Support Section was updated. Obsolete SKUs were removed. | |
| 02-Apr-2019 | Changed | Related Options Section was updated. Obsolete SKUs were removed. | |
| 03-Dec-2018 | Changed | Related Options Section was updated | |
| 15-Oct-2018 | Changed | Technical Specifications section was updated | |
| 01-Oct-2018 | Changed | Standard Features section was updated | |
| 02-Jul-2018 | Changed | Related options & Technical Specifications section was updated | |
| 05-Feb-2018 | Changed | Rack Models, Standard Features, and Technical Specifications were updated. | |
| 07-Aug-2017 | Added | Added new Baying kits and Door kits. | |
| Changed | Related Options section was revised. | ||
| 27-Mar-2017 | Changed | Standard Features, Related Options and Technical Specifications were updated. | |
| 13-Feb-2017 | Changed | Reliability/Durability and Sidewall Panel Kits were revised. | |
| 13-Jan-2017 | Changed | Description for P9L17A was changed. Front left image was updated. | |
| 28-Nov-2016 | Added | New QuickSpecs |
© Copyright 2026 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.
c05324689, 15754 - Worldwide - V14 - 16-February-2026
