HPE InfiniBand NDR Cables
These cables are qualified as InfiniBand and Ethernet enabled.
InfiniBand NDR Direct Attach Copper cables (DAC) and InfiniBand NDR Active Copper cables (ACC) are the lowest cost cabling choice to create high-speed, low-latency connections in an InfiniBand NDR solution. These cables are offered in various lengths and as OSFP and QSFP112 types. Passive DACs use copper wires without any electronics as the connection. These cables consume zero power and have the lowest latency and insertion loss. InfiniBand Active Copper Cables include signal-boosting integrated circuits (ICs) in the cable end to extend their reach.
Overview
NDR optical interconnect is enabled through NDR transceivers usage with fiber cables. NDR transceivers for switches are dual ported and support two NDR links. NDR transceivers for Host Channel Adapters (HCAs) are single ported. Connection between NDR switches and HDR/HDR100 adapters is enabled with Active Optical Cable (AOC) providing OSFP to dual QSFP.
These cables meet the InfiniBand Trade Association (IBTA) standards and are designed for use in supercomputers that have the most stringent requirements.
![[IMAGE1]](https://assets.ext.hpe.com/is/image/hpedam/a50006974enw_block1img?$crimg$ "[IMAGE1]")
Models | |
| InfiniBand Direct Attach Copper Cables | |
| HPE InfiniBand NDR/Ethernet OSFP to OSFP 1m Switch-Switch Direct Attach Copper Cable | P45696-B22 |
| HPE InfiniBand NDR/Ethernet OSFP to OSFP 1.5m Switch-Switch Direct Attach Copper Cable | P45696-B23 |
| HPE InfiniBand NDR/Ethernet OSFP to OSFP 2m Switch-Switch Direct Attach Copper Cable | P45696-B24 |
| HPE InfiniBand NDR200/Ethernet OSFP to 4xOSFP 1m Splitter Direct Attach Copper Cable | P45698-B22 |
| HPE InfiniBand NDR200/Ethernet OSFP to 4xOSFP 1.5m Splitter Direct Attach Copper Cable | P45698-B23 |
| HPE InfiniBand NDR200/Ethernet OSFP to 4xOSFP 2.5m Splitter Direct Attach Copper Cable | P45698-B25 |
| HPE InfiniBand NDR200/Ethernet OSFP to 4xOSFP 3m Splitter Direct Attach Copper Cable | P45698-B26 |
| HPE InfiniBand NDR/Ethernet OSFP to 2xOSFP 1m Splitter Direct Attach Copper Cable | P45697-B22 |
| HPE InfiniBand NDR/Ethernet OSFP to 2xOSFP 1.5m Splitter Direct Attach Copper Cable | P45697-B23 |
| HPE InfiniBand NDR/Ethernet OSFP to 2xOSFP 2m Splitter Direct Attach Copper Cable | P45697-B24 |
| HPE InfiniBand NDR/Ethernet OSFP to 2xOSFP 2.5m Splitter Direct Attach Copper Cable | P45697-B25 |
| HPE InfiniBand NDR/Ethernet OSFP to 2xOSFP 3m Splitter Direct Attach Copper Cable | P45697-B26 |
| HPE InfiniBand NDR200/Ethernet OSFP to 4xQSFP112 1m Direct Attach Copper Cable | P65335-B21 |
| HPE InfiniBand NDR200/Ethernet OSFP to 4xQSFP112 2m Direct Attach Copper Cable | P65335-B23 |
| HPE InfiniBand NDR200/Ethernet OSFP to 4xQSFP112 3m Direct Attach Copper Cable | P65335-B25 |
| HPE InfiniBand NDR/Ethernet OSFP to 2xQSFP112 1m Splitter Direct Attach Copper Cable | P70511-B21 |
| HPE InfiniBand NDR/Ethernet OSFP to 2xQSFP112 2m Splitter Direct Attach Copper Cable | P70511-B22 |
| HPE InfiniBand NDR/Ethernet OSFP to 2xQSFP112 3m Splitter Direct Attach Copper Cable | P70511-B23 |
| Notes: − Switch-Switch cables may only be used to connect between NDR switches. Splitter cables may only be used to connect switches to Host Channel Adapters (HCAs) − Switch-side transceivers may only be used in NDR switch ports. HCA-side transceivers may only be used in HCA ports − Multi-mode and single-mode MUST not be mixed. Multi-mode transceivers MUST be used with Multi-mode fiber cables. Single-mode transceiver MUST be used with Single-mode fibers | |
| InfiniBand Active Copper Cables | |
| HPE InfiniBand NDR/Ethernet OSFP to OSFP 3m Switch-Switch Active Copper Cable | P55189-B21 |
| HPE InfiniBand NDR/Ethernet OSFP to OSFP 4m Switch-Switch Active Copper Cable | P55189-B22 |
| HPE InfiniBand NDR/Ethernet OSFP to OSFP 5m Switch-Switch Active Copper Cable | P55189-B23 |
| HPE InfiniBand NDR200/Ethernet OSFP to 4xOSFP 4m Splitter Active Copper Cable | P50397-B21 |
| HPE InfiniBand NDR/Ethernet OSFP to 2xOSFP 4m Splitter Active Copper Cable | P50396-B21 |
| HPE InfiniBand NDR/Ethernet OSFP to 2xOSFP 5m Splitter Active Copper Cable | P50396-B22 |
| HPE InfiniBand NDR/Ethernet OSFP to 2xQSFP112 4m Splitter Active Copper Cable | P70512-B21 |
| HPE InfiniBand NDR/Ethernet OSFP to 2xQSFP112 5m Splitter Active Copper Cable | P70512-B22 |
| Notes: – Switch-Switch cables may only be used to connect between NDR switches. Splitter cables may only be used to connect switches to Host Channel Adapters (HCAs) – Switch-side transceivers may only be used in NDR switch ports. HCA-side transceivers may only be used in HCA ports – Multi-mode and single-mode MUST not be mixed. Multi-mode transceivers MUST be used with Multi-mode fiber cables. Single-mode transceiver MUST be used with Single-mode fibers – Both OSFP and QSFP112 ends of the cable are based on the CMIS management interface | |
| InfiniBand Single Mode Optical Transceiver | |
| HPE InfiniBand NDR/Ethernet 2x400Gb OSFP Single-mode 100m Switch-side Transceiver | P45693-B21 |
| HPE InfiniBand NDR/Ethernet 400Gb OSFP 1-port Single-mode 100m HCA-side Flat-Top Transceiver | P87585-B21 |
| Notes: – Switch-Switch cables may only be used to connect between NDR switches. Splitter cables may only be used to connect switches to Host Channel Adapters (HCAs) – Switch-side transceivers may only be used in NDR switch ports. HCA-side transceivers may only be used in HCA ports – Multi-mode and single-mode MUST not be mixed. Multi-mode transceivers MUST be used with Multi-mode fiber cables. Single-mode transceiver MUST be used with Single-mode fibers – Only supported from switch to switch. There is no switch to HCA support using single mode fiber. – These transceivers have MPO-12/APC (Angled Polished Connectors) | |
| InfiniBand Single Mode Multi Fiber Push On | |
| HPE InfiniBand NDR/Ethernet 8 Fiber MPO to 8 Fiber MPO Single-mode 3m Cable | P45731-B21 |
| HPE InfiniBand NDR/Ethernet 8 Fiber MPO to 8 Fiber MPO Single-mode 10m Cable | P45731-B23 |
| HPE InfiniBand NDR/Ethernet 8 Fiber MPO to 8 Fiber MPO Single-mode 15m Cable | P45731-B24 |
| HPE InfiniBand NDR/Ethernet 8 Fiber MPO to 8 Fiber MPO Single-mode 20m Cable | P45731-B25 |
| Notes: – Switch-Switch cables may only be used to connect between NDR switches. Splitter cables may only be used to connect switches to Host Channel Adapters (HCAs) – Switch-side transceivers may only be used in NDR switch ports. HCA-side transceivers may only be used in HCA ports – Multi-mode and single-mode MUST not be mixed. Multi-mode transceivers MUST be used with Multi-mode fiber cables. Single-mode transceiver MUST be used with Single-mode fibers – These cables have MPO-12/ APC (Angled Polished Connectors) | |
| InfiniBand Multi Mode Optical Transceiver | |
| HPE InfiniBand NDR/Ethernet 2x400Gb OSFP Multi-mode 50m Switch-side Transceiver | P49762-B21 |
| HPE InfiniBand NDR/Ethernet 1x400Gb OSFP Multi-mode 50m HCA-side Transceiver | P49764-B21 |
| HPE InfiniBand NDR/Ethernet 400G QSFP112 MPO12 850nm Multi-mode 50m APC Transceiver | P65334-B21 |
| HPE InfiniBand NDR/Ethernet 400Gb OSFP 1-port Single-mode 100m HCA-side Flat-Top Transceiver | P87585-B21 |
| Notes: – Switch-Switch cables may only be used to connect between NDR switches. Splitter cables may only be used to connect switches to Host Channel Adapters (HCAs) – Switch-side transceivers may only be used in NDR switch ports. HCA-side transceivers may only be used in HCA ports – Multi-mode and single-mode MUST not be mixed. Multi-mode transceivers MUST be used with Multi-mode fiber cables. Single-mode transceiver MUST be used with Single-mode fibers – These transceivers have MPO-12/ APC (Angled Polished Connectors) | |
| InfiniBand Multi Mode Fiber Push On | |
| HPE InfiniBand NDR/Ethernet 8 Fiber MPO to 8 Fiber MPO Multi-mode 3m Cable | P49765-B21 |
| HPE InfiniBand NDR/Ethernet 8 Fiber MPO to 8 Fiber MPO Multi-mode 5m Cable | P49765-B22 |
| HPE InfiniBand NDR/Ethernet 8 Fiber MPO to 8 Fiber MPO Multi-mode 10m Cable | P49765-B23 |
| HPE InfiniBand NDR/Ethernet 8 Fiber MPO to 8 Fiber MPO Multi-mode 15m Cable | P49765-B24 |
| HPE InfiniBand NDR/Ethernet 8 Fiber MPO to 8 Fiber MPO Multi-mode 20m Cable | P49765-B25 |
| HPE InfiniBand NDR/Ethernet 8 Fiber MPO to 8 Fiber MPO Multi-mode 30m Cable | P49765-B26 |
| HPE InfiniBand NDR200/Ethernet 8 Fiber MPO to 2x4 Fiber MPO Multi-mode 5m Splitter Cable | P49766-B22 |
| HPE InfiniBand NDR200/Ethernet 8 Fiber MPO to 2x4 Fiber MPO Multi-mode 10m Splitter Cable | P49766-B23 |
| HPE InfiniBand NDR200/Ethernet 8 Fiber MPO to 2x4 Fiber MPO Multi-mode 15m Splitter Cable | P49766-B24 |
| HPE InfiniBand NDR200/Ethernet 8 Fiber MPO to 2x4 Fiber MPO Multi-mode 20m Splitter Cable | P49766-B25 |
| Notes: – Switch-Switch cables may only be used to connect between NDR switches. Splitter cables may only be used to connect switches to Host Channel Adapters (HCAs) – Switch-side transceivers may only be used in NDR switch ports. HCA-side transceivers may only be used in HCA ports – Multi-mode and single-mode MUST not be mixed. Multi-mode transceivers MUST be used with Multi-mode fiber cables. Single-mode transceiver MUST be used with Single-mode fibers – These cables have MPO-12/ APC (Angled Polished Connectors) | |
